Mfr. Part #	Availability	Quantity	Datasheet	Packaging	Series	ProductStatus	DiodeConfiguration	DiodeType	Voltage-DCReverse(Vr)(Max)	Current-AverageRectified(Io)(perDiode)	Voltage-Forward(Vf)(Max)@If	Speed	ReverseRecoveryTime(trr)	Current-ReverseLeakage@Vr	OperatingTemperature-Junction	MountingType
CPT600100D DIODE MODULE 100V TO244AB Microsemi Corporation	3,816	RFQ	Datasheet	Bulk	-	Obsolete	1 Pair Series Connection	Schottky	100 V	300A	850 mV @ 300 A	Fast Recovery =< 500ns, > 200mA (Io)	-	8 mA @ 100 V	-	Chassis Mount
FST16090A DIODE MODULE 90V TO249 Microsemi Corporation	2,555	RFQ	Datasheet	Bulk	-	Obsolete	1 Pair Common Anode	Schottky	90 V	80A	960 mV @ 80 A	Fast Recovery =< 500ns, > 200mA (Io)	-	2 mA @ 90 V	-	Screw Mount
MSAD165-18 DIODE MODULE 1.8KV 165A D2 Microsemi Corporation	3,326	RFQ	Datasheet	Bulk	-	Obsolete	1 Pair Common Anode	Standard	1800 V	165A	1.4 V @ 300 A	Standard Recovery >500ns, > 200mA (Io)	-	9 mA @ 1800 V	-	Chassis Mount
MSAD70-16 DIODE MODULE 1.6KV 70A D1 Microsemi Corporation	2,966	RFQ	Datasheet	Bulk	-	Obsolete	1 Pair Common Anode	Standard	1600 V	70A	1.48 V @ 200 A	Standard Recovery >500ns, > 200mA (Io)	-	5 mA @ 1600 V	-	Chassis Mount
UFT20120 DIODE MODULE 200V 100A Microsemi Corporation	2,850	RFQ	Datasheet	Bulk	-	Obsolete	1 Pair Common Cathode	Standard	200 V	100A	1.25 V @ 100 A	Fast Recovery =< 500ns, > 200mA (Io)	70 ns	50 µA @ 200 V	-	Screw Mount
APTDC902U601G DIODE MODULE 600V 90A SP1 Microsemi Corporation	2,224	RFQ		Bulk	-	Obsolete	2 Independent	Silicon Carbide Schottky	600 V	90A	1.8 V @ 90 A	No Recovery Time > 500mA (Io)	0 ns	1800 µA @ 600 V	-40°C ~ 175°C	Chassis Mount
UFT7260SM3A DIODE MODULE 600V 35A SM3 Microsemi Corporation	3,054	RFQ		Bulk	-	Obsolete	1 Pair Common Anode	Standard	600 V	35A	1.35 V @ 35 A	Fast Recovery =< 500ns, > 200mA (Io)	75 ns	25 µA @ 600 V	-	Chassis Mount
UFT7260SM3C DIODE MODULE 600V 35A SM3 Microsemi Corporation	2,598	RFQ		Bulk	-	Obsolete	1 Pair Common Cathode	Standard	600 V	35A	1.35 V @ 35 A	Fast Recovery =< 500ns, > 200mA (Io)	75 ns	25 µA @ 600 V	-	Chassis Mount
UFT7260SM3D DIODE MODULE 600V 35A SM3 Microsemi Corporation	3,827	RFQ		Bulk	-	Obsolete	1 Pair Series Connection	Standard	600 V	35A	1.35 V @ 35 A	Fast Recovery =< 500ns, > 200mA (Io)	75 ns	25 µA @ 600 V	-	Chassis Mount
UFT7260SM4C DIODE MODULE 600V 35A SM4 Microsemi Corporation	3,343	RFQ		Bulk	-	Obsolete	1 Pair Common Cathode	Standard	600 V	35A	1.35 V @ 35 A	Fast Recovery =< 500ns, > 200mA (Io)	75 ns	25 µA @ 600 V	-	Chassis Mount
UFT7260SM4D DIODE MODULE 600V 35A SM4 Microsemi Corporation	3,235	RFQ		Bulk	-	Obsolete	1 Pair Series Connection	Standard	600 V	35A	1.35 V @ 35 A	Fast Recovery =< 500ns, > 200mA (Io)	75 ns	25 µA @ 600 V	-	Chassis Mount
UFT7260SM5A DIODE MODULE 600V 35A SM5 Microsemi Corporation	2,146	RFQ		Bulk	-	Obsolete	1 Pair Common Anode	Standard	600 V	35A	1.35 V @ 35 A	Fast Recovery =< 500ns, > 200mA (Io)	75 ns	25 µA @ 600 V	-	Chassis Mount
UFT7260SM6A DIODE MODULE 600V 35A SM6 Microsemi Corporation	3,023	RFQ		Bulk	-	Obsolete	1 Pair Common Anode	Standard	600 V	35A	1.35 V @ 35 A	Fast Recovery =< 500ns, > 200mA (Io)	75 ns	25 µA @ 600 V	-	Chassis Mount
UFT7260SM6C DIODE MODULE 600V 35A SM6 Microsemi Corporation	2,679	RFQ		Bulk	-	Obsolete	1 Pair Common Cathode	Standard	600 V	35A	1.35 V @ 35 A	Fast Recovery =< 500ns, > 200mA (Io)	75 ns	25 µA @ 600 V	-	Chassis Mount
UFT7260SM6D DIODE MODULE 600V 35A SM6 Microsemi Corporation	2,324	RFQ		Bulk	-	Obsolete	1 Pair Series Connection	Standard	600 V	35A	1.35 V @ 35 A	Fast Recovery =< 500ns, > 200mA (Io)	75 ns	25 µA @ 600 V	-	Chassis Mount
APT2X20DC120J DIODE MODULE 1.2KV 20A SOT227 Microsemi Corporation	3,582	RFQ		Bulk	-	Active	2 Independent	Silicon Carbide Schottky	1200 V	20A	1.8 V @ 20 A	No Recovery Time > 500mA (Io)	0 ns	400 µA @ 1200 V	-55°C ~ 175°C	Chassis Mount
APT2X30DC120J DIODE MODULE 1.2KV 30A SOT227 Microsemi Corporation	2,940	RFQ		Bulk	-	Obsolete	2 Independent	Silicon Carbide Schottky	1200 V	30A	1.8 V @ 30 A	No Recovery Time > 500mA (Io)	0 ns	600 µA @ 1200 V	-	Chassis Mount
APT2X30DC60J DIODE MODULE 600V 30A SOT227 Microsemi Corporation	3,955	RFQ		Bulk	-	Active	2 Independent	Silicon Carbide Schottky	600 V	30A	1.8 V @ 30 A	No Recovery Time > 500mA (Io)	0 ns	600 µA @ 600 V	-	Chassis Mount
APT2X31DC120J DIODE MODULE 1.2KV 30A SOT227 Microsemi Corporation	2,956	RFQ		Bulk	-	Obsolete	2 Independent	Silicon Carbide Schottky	1200 V	30A	1.8 V @ 30 A	No Recovery Time > 500mA (Io)	0 ns	600 µA @ 1200 V	-	Chassis Mount
APT2X31DC60J DIODE MODULE 600V 30A SOT227 Microsemi Corporation	2,913	RFQ		Bulk	-	Active	2 Independent	Silicon Carbide Schottky	600 V	30A	1.8 V @ 30 A	No Recovery Time > 500mA (Io)	0 ns	600 µA @ 600 V	-	Chassis Mount
