| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | DiodeConfiguration | DiodeType | Voltage-DCReverse(Vr)(Max) | Current-AverageRectified(Io)(perDiode) | Voltage-Forward(Vf)(Max)@If | Speed | ReverseRecoveryTime(trr) | Current-ReverseLeakage@Vr | OperatingTemperature-Junction | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
113CNQ100DIODE SCHOTTKY 100V 110A PRM2 |
2,934 | 16.14 |
RFQ |
Datasheet |
Box | - | Active | 1 Pair Common Cathode | Schottky | 100 V | 55A | 810 mV @ 55 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 1 mA @ 100 V | -55°C ~ 175°C | Chassis Mount |
|
SK2U150-400DIODE RECTIFIER 400V 150A SOT-22 |
2,215 | 22.77 |
RFQ |
Datasheet |
Box | - | Active | 2 Independent | Standard | 400 V | 75A | 1.1 V @ 75 A | Fast Recovery =< 500ns, > 200mA (Io) | 150 ns | 50 µA @ 400 V | -55°C ~ 150°C | Chassis Mount |
|
|
83CNQ080DIODE SCHOTTKY 80V 40A PRM2 |
2,380 | 22.82 |
RFQ |
Datasheet |
Bulk | - | Active | 1 Pair Common Cathode | Schottky | 80 V | 40A | 1 V @ 40 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 1.5 mA @ 80 V | -55°C ~ 175°C | Chassis Mount |
|
|
83CNQ100S2DIODE ARRAY SCHOTTKY 100V PRM2 |
3,776 | 23.23 |
RFQ |
Datasheet |
Bulk | - | Active | 1 Pair Common Cathode | Schottky | 100 V | 80A | 1 V @ 80 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 1.5 mA @ 100 V | -55°C ~ 175°C | Chassis Mount |
|
|
SK2U200-400DIODE RECTIFIER 400V 200A SOT-22 |
3,256 | 25.05 |
RFQ |
Datasheet |
Box | - | Active | 2 Independent | Standard | 400 V | 120A (DC) | 1.15 V @ 100 A | Fast Recovery =< 500ns, > 200mA (Io) | 150 ns | 50 µA @ 400 V | -55°C ~ 175°C | Chassis Mount |
|
SM090KD800G1DIODE RECTIFIER 800V 90A DOUBLE |
3,036 | 28.30 |
RFQ |
Datasheet |
Box | - | Active | 1 Pair Series Connection | Standard | 800 V | 100A | 1.15 V @ 100 A | Standard Recovery >500ns, > 200mA (Io) | - | 20 µA @ 800 V | -40°C ~ 150°C | Chassis Mount |
;;.jpg)
|
406CMQ200RDIODE SCHOTTKY 200V 400A PRM4-IS |
3,132 | 39.18 |
RFQ |
Datasheet |
Box | - | Active | 1 Pair Common Anode | Schottky | 200 V | 200A | 990 mV @ 200 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 10 mA @ 200 V | -55°C ~ 175°C | Chassis Mount |
|
SM165KD800G2DIODE RECTIFIER 800V 165A DOUBLE |
2,629 | 39.38 |
RFQ |
Datasheet |
Box | - | Active | 1 Pair Series Connection | Standard | 800 V | 165A | 1.25 V @ 165 A | Standard Recovery >500ns, > 200mA (Io) | - | 20 µA @ 800 V | -40°C ~ 150°C | Chassis Mount |
|
|
403DMQ100DIODE SCHOTTKY 100V 400A PRM4-IS |
2,475 | 41.08 |
RFQ |
Datasheet |
Box | - | Active | 1 Pair Series Connection | Schottky | 100 V | 200A | 830 mV @ 200 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 6 mA @ 100 V | -55°C ~ 175°C | Chassis Mount |
|
|
209CMQ150DIODE SCHOTTKY 150V 100A PRM4 |
3,168 | 64.02 |
RFQ |
Datasheet |
Bulk | - | Active | 1 Pair Common Cathode | Schottky | 150 V | 100A | 1.03 V @ 100 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 3 mA @ 150 V | -55°C ~ 175°C | Chassis Mount |
|
|
220CMQ030DIODE SCHOTTKY 30V 110A PRM4 |
3,048 | 64.02 |
RFQ |
Datasheet |
Bulk | - | Active | 1 Pair Common Cathode | Schottky | 30 V | 110A | 480 mV @ 110 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 10 mA @ 30 V | -55°C ~ 150°C | Chassis Mount |
|
BAV70DIODE ARRAY GP 75V 150MA SOT23 |
3,167 | 0.24 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Common Cathode | Standard | 75 V | 150mA | 1 V @ 50 mA | Fast Recovery =< 500ns, > 200mA (Io) | 6 ns | 2.5 µA @ 75 V | -65°C ~ 150°C | Surface Mount |
|
20CJQ0302A, 30V, SOT-223, SCHOTTKY RECTI |
2,236 | 0.52 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Common Cathode | Schottky | 30 V | 2A | 690 mV @ 2 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 100 µA @ 30 V | -55°C ~ 150°C | Surface Mount |
|
MBRF1080CTRDIODE ARRAY SCHOTTKY 80V ITO220 |
878 | 0.67 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Anode | Schottky | 80 V | - | 850 mV @ 5 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 1 mA @ 80 V | -55°C ~ 150°C | Through Hole |
|
|
SDURF1020CTRDIODE ARRAY GP 200V ITO220AB |
347 | 0.67 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Anode | Standard | 200 V | - | 975 mV @ 5 A | Fast Recovery =< 500ns, > 200mA (Io) | 35 ns | 10 µA @ 200 V | -55°C ~ 150°C | Through Hole |
|
MBR1060CTPDIODE ARRAY SCHOTTKY 60V TO220AB |
955 | 0.75 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Cathode | Schottky | 60 V | - | 700 mV @ 5 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 1 mA @ 60 V | -55°C ~ 150°C | Through Hole |
|
|
MBR1045CTPDIODE ARRAY SCHOTTKY 45V TO220AB |
724 | 0.75 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Cathode | Schottky | 45 V | - | 700 mV @ 5 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 1 mA @ 45 V | -55°C ~ 150°C | Through Hole |
|
SDURB1040CTDIODE ARRAY GEN PURP 400V D2PAK |
567 | 0.75 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Common Cathode | Standard | 400 V | - | 1.3 V @ 5 A | Fast Recovery =< 500ns, > 200mA (Io) | 45 ns | 30 µA @ 400 V | -55°C ~ 150°C | Surface Mount |
|
|
MBRB10100CTDIODE ARRAY SCHOTTKY 100V D2PAK |
248 | 0.75 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Common Cathode | Schottky | 100 V | - | 850 mV @ 5 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 1 mA @ 100 V | -55°C ~ 150°C | Surface Mount |
|
|
SDURB1030CTDIODE ARRAY GEN PURP 300V D2PAK |
800 | 0.77 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Common Cathode | Standard | 300 V | - | 1.3 V @ 5 A | Fast Recovery =< 500ns, > 200mA (Io) | 45 ns | 30 µA @ 300 V | -55°C ~ 150°C | Surface Mount |
