| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | RoHS | Speed | Diode Type | Part Status | Mounting Type | Capacitance @ Vr, F | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Operating Temperature | Voltage - Forward (Vf) (Max) @ If |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
VS-8ETU12-N3DIODE GEN PURP 1.2KV 8A TO220AC |
2,495 | 0.00 |
RFQ |
Datasheet |
Tube | FRED Pt® | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Obsolete | Through Hole | - | 144 ns | 55 µA @ 1200 V | 1200 V | 8A | -55°C ~ 175°C | 2.55 V @ 8 A |
|
|
VS-ETU3006FP-M3RDIODE |
3,236 | 0.00 |
RFQ |
Datasheet |
Tube | RoHS | - | - | Active | - | - | - | - | - | - | - | - | |
|
VSSA3L6S-01M3/61TDIODE SCHOTTKY |
2,884 | 0.00 |
RFQ |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Obsolete | Surface Mount | 395pF @ 4V, 1MHz | - | 1.5 mA @ 60 V | 60 V | 2.5A | -55°C ~ 150°C | 580 mV @ 3 A | ||
|
UF4005-E3S/73DIODE GEN PURP 600V |
2,140 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Obsolete | Through Hole | 17pF @ 4V, 1MHz | 75 ns | 10 µA @ 600 V | 600 V | 1A | -55°C ~ 150°C | 1.7 V @ 1 A | |
|
RGL41J-7002E3/97DIODE GEN PURP 600V |
2,424 | 0.00 |
RFQ |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Obsolete | Surface Mount | 15pF @ 4V, 1MHz | 250 ns | 5 µA @ 600 V | 600 V | 1A | -65°C ~ 175°C | 1.3 V @ 1 A | ||
.jpg)
|
US1J-M3S/61TDIODE GEN PURP 600V |
2,715 | 0.00 |
RFQ |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Obsolete | Surface Mount | 10pF @ 4V, 1MHz | 75 ns | 10 µA @ 600 V | 600 V | 1A | -55°C ~ 150°C | 1.7 V @ 1 A | ||
|
SB3H100L-5700E3/72DIODE SCHOTTKY |
2,879 | 0.00 |
RFQ |
Tape & Reel (TR) | RoHS | - | - | Obsolete | - | - | - | - | - | - | - | - | ||
.jpg)
|
SS2P6-01HM3/85ADIODE SCHOTTKY |
2,385 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | Automotive, AEC-Q101 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Obsolete | Surface Mount | 80pF @ 4V, 1MHz | - | 100 µA @ 60 V | 60 V | 2A | -55°C ~ 150°C | 700 mV @ 2 A |
|
|
SS2P6-01HM3/84ADIODE SCHOTTKY |
2,988 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | Automotive, AEC-Q101 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Obsolete | Surface Mount | 80pF @ 4V, 1MHz | - | 100 µA @ 60 V | 60 V | 2A | -55°C ~ 150°C | 700 mV @ 2 A |
|
GF1G-9HE3_A/HDIODE GENERAL PURPOSE |
2,639 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | Automotive, AEC-Q101, Superectifier® | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Obsolete | Surface Mount | 15pF @ 4V, 1MHz | 2 µs | 5 µA @ 400 V | 400 V | 1A | -65°C ~ 175°C | 1.1 V @ 1 A |
|
|
EGP10FE-E3/54DIODE RECTIFIER |
3,059 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Obsolete | Through Hole | 15pF @ 4V, 1MHz | 50 ns | 5 µA @ 300 V | 300 V | 1A | -65°C ~ 150°C | 1.25 V @ 1 A | |
|
SB360-5300E3/73DIODE SCHOTTKY |
2,920 | 0.00 |
RFQ |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Obsolete | Through Hole | - | - | 500 µA @ 60 V | 60 V | 3A | -65°C ~ 150°C | 680 mV @ 3 A | ||
|
SL23-7001HE3_A/IDIODE SCHOTTKY |
3,711 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | Automotive, AEC-Q101 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Obsolete | Surface Mount | - | - | 400 µA @ 30 V | 30 V | 2A | -55°C ~ 125°C | 440 mV @ 2 A |
|
NSF8ATHE3_B/PDIODE GENERAL PURPOSE |
2,816 | 0.00 |
RFQ |
Tape & Reel (TR) | Automotive, AEC-Q101 | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Obsolete | Through Hole | 55pF @ 4V, 1MHz | - | 10 µA @ 50 V | 50 V | 8A | -55°C ~ 150°C | 1.1 V @ 8 A | |
|
|
GF1G-9HE3_A/IDIODE GENERAL PURPOSE |
3,915 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | Automotive, AEC-Q101, Superectifier® | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Obsolete | Surface Mount | 15pF @ 4V, 1MHz | 2 µs | 5 µA @ 400 V | 400 V | 1A | -65°C ~ 175°C | 1.1 V @ 1 A |
|
|
US1J-E3S/61TDIODE GEN PURP 600V |
3,012 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Obsolete | Surface Mount | 10pF @ 4V, 1MHz | 75 ns | 10 µA @ 600 V | 600 V | 1A | -55°C ~ 150°C | 1.7 V @ 1 A | |
|
V15PN50-5700M3/86ADIODE SCHOTTKY 50V 15A |
3,429 | 0.00 |
RFQ |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Obsolete | Surface Mount | - | - | 3 mA @ 50 V | 50 V | 15A | -40°C ~ 150°C | 560 mV @ 15 A | ||
|
|
EGP10AE-E3/54DIODE RECTIFIER |
2,072 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Obsolete | Through Hole | 22pF @ 4V, 1MHz | 50 ns | 5 µA @ 50 V | 50 V | 1A | -65°C ~ 150°C | 950 mV @ 1 A | |
|
|
NSF8AT-E3/45DIODE GENERAL PURPOSE |
3,183 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Obsolete | Through Hole | 55pF @ 4V, 1MHz | - | 10 µA @ 50 V | 50 V | 8A | -55°C ~ 150°C | 1.1 V @ 8 A | |
|
|
S1J-6605E3/61TDIODE GEN PURP 600V |
2,827 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | Automotive, AEC-Q101 | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Obsolete | Surface Mount | 12pF @ 4V, 1MHz | 1.8 µs | 1 µA @ 600 V | 600 V | 1A | -55°C ~ 150°C | 1.1 V @ 1 A |
