Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	RoHS	Speed	Diode Type	Part Status	Mounting Type	Capacitance @ Vr, F	Reverse Recovery Time (trr)	Current - Reverse Leakage @ Vr	Voltage - DC Reverse (Vr) (Max)	Current - Average Rectified (Io)	Operating Temperature	Voltage - Forward (Vf) (Max) @ If
E1780TG65E DIODE GEN PURP 3.6KV 1780A - IXYS	2,180	1499.85	RFQ	Datasheet	Box	SONIC-FRD™	RoHS	Standard Recovery >500ns, > 200mA (Io)	Standard	Active	Chassis Mount	-	1.22 µs	100 mA @ 3600 V	3600 V	1780A	-40°C ~ 140°C	3.83 V @ 1.78 kA
W3842MC280 RECTIFIER DIODE IXYS	2,748	184.50	RFQ		Bulk		RoHS	Standard Recovery >500ns, > 200mA (Io)	Standard	Active	Chassis Mount	-	34 µs	50 mA @ 2800 V	2800 V	3842A	-40°C ~ 160°C	1.2 V @ 3000 A
MDD810-16N2 DIODE DUAL 1600V 807A IXYS	3,048	185.70	RFQ		Box		RoHS	-	-	Active	-	-	-	-	-	-	-	-
W3708MC320 RECTIFIER DIODE IXYS	2,434	188.70	RFQ		Bulk		RoHS	Standard Recovery >500ns, > 200mA (Io)	Standard	Active	Chassis Mount	-	37 µs	100 mA @ 3200 V	3200 V	3753A	-40°C ~ 160°C	1.27 V @ 3000 A
W3708MC350 RECTIFIER DIODE IXYS	3,196	192.60	RFQ		Bulk		RoHS	Standard Recovery >500ns, > 200mA (Io)	Standard	Active	Chassis Mount	-	37 µs	100 mA @ 3500 V	3500 V	3753A	-40°C ~ 160°C	1.27 V @ 3000 A
M1583VF450 FAST DIODE IXYS	2,074	580.65	RFQ		Bulk		RoHS	Standard Recovery >500ns, > 200mA (Io)	Standard	Active	Chassis Mount	-	5 µs	150 mA @ 4500 V	4500 V	1583A	-40°C ~ 150°C	2.8 V @ 2000 A
W2054NC420 RECTIFIER DIODE IXYS	3,191	202.20	RFQ		Bulk		RoHS	Standard Recovery >500ns, > 200mA (Io)	Standard	Active	Chassis Mount	-	-	50 mA @ 4200 V	4200 V	2055A	-40°C ~ 160°C	1.7 V @ 3000 A
M1565VF450 FAST DIODE IXYS	2,978	606.75	RFQ		Bulk		RoHS	Standard Recovery >500ns, > 200mA (Io)	Standard	Active	Chassis Mount	-	5 µs	100 mA @ 4500 V	4500 V	1565A	-40°C ~ 125°C	1.8 V @ 2000 A
W1730JK280 RECTIFIER DIODE IXYS	3,912	104.94	RFQ		Bulk		RoHS	Standard Recovery >500ns, > 200mA (Io)	Standard	Active	Chassis Mount	-	-	30 mA @ 2800 V	2800 V	1730A	-40°C ~ 160°C	1.2 V @ 1000 A
W1980JK180 RECTIFIER DIODE IXYS	2,102	100.90	RFQ		Bulk		RoHS	Standard Recovery >500ns, > 200mA (Io)	Standard	Active	Chassis Mount	-	-	30 mA @ 1800 V	1800 V	1980A	-40°C ~ 175°C	1.12 V @ 1000 A
M0759YC120 FAST DIODE IXYS	3,938	114.04	RFQ		Bulk		RoHS	Standard Recovery >500ns, > 200mA (Io)	Standard	Active	Chassis Mount	-	2 µs	50 mA @ 1200 V	1200 V	759A	-40°C ~ 125°C	1.7 V @ 1500 A
W1975MC650 RECTIFIER DIODE IXYS	2,260	263.10	RFQ		Bulk		RoHS	Standard Recovery >500ns, > 200mA (Io)	Standard	Active	Chassis Mount	-	45 µs	100 mA @ 6500 V	6500 V	1975A	-40°C ~ 150°C	3.95 V @ 4200 A
W1730JK240 RECTIFIER DIODE IXYS	2,129	102.68	RFQ		Bulk		RoHS	Standard Recovery >500ns, > 200mA (Io)	Standard	Active	Chassis Mount	-	-	30 mA @ 2400 V	2400 V	1730A	-40°C ~ 160°C	1.2 V @ 1000 A
W1975MC680 RECTIFIER DIODE IXYS	2,194	265.95	RFQ		Bulk		RoHS	Standard Recovery >500ns, > 200mA (Io)	Standard	Active	Chassis Mount	-	45 µs	100 mA @ 6800 V	6800 V	1975A	-40°C ~ 150°C	3.95 V @ 4200 A
W3082MC420 RECTIFIER DIODE IXYS	2,599	205.50	RFQ		Bulk		RoHS	Standard Recovery >500ns, > 200mA (Io)	Standard	Active	Chassis Mount	-	45 µs	50 mA @ 4200 V	4200 V	3120A	-40°C ~ 160°C	2.58 V @ 8600 A
W2054NC450 RECTIFIER DIODE IXYS	2,081	206.40	RFQ		Bulk		RoHS	Standard Recovery >500ns, > 200mA (Io)	Standard	Active	Chassis Mount	-	-	50 mA @ 4500 V	4500 V	2055A	-40°C ~ 160°C	1.7 V @ 3000 A
W1856NC460 RECTIFIER DIODE IXYS	2,509	209.55	RFQ		Bulk		RoHS	Standard Recovery >500ns, > 200mA (Io)	Standard	Active	Chassis Mount	-	36 µs	50 mA @ 4600 V	4600 V	1856A	-40°C ~ 160°C	2.95 V @ 5550 A
W3082MC450 RECTIFIER DIODE IXYS	3,757	209.70	RFQ		Bulk		RoHS	Standard Recovery >500ns, > 200mA (Io)	Standard	Active	Chassis Mount	-	45 µs	50 mA @ 4500 V	4500 V	3120A	-40°C ~ 160°C	2.58 V @ 8600 A
M2505MC200 FAST DIODE IXYS	2,494	275.07	RFQ		Bulk		RoHS	Standard Recovery >500ns, > 200mA (Io)	Standard	Active	Chassis Mount	-	7.6 µs	-	2000 V	2505A	-	991 mV @ 2000 A
M1104NC450 FAST DIODE IXYS	3,446	275.54	RFQ		Bulk		RoHS	Standard Recovery >500ns, > 200mA (Io)	Standard	Active	Chassis Mount	-	6 µs	50 mA @ 4500 V	4500 V	1104A	-40°C ~ 125°C	2.2 V @ 1500 A
