| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | RoHS | Speed | Diode Type | Part Status | Mounting Type | Capacitance @ Vr, F | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Operating Temperature | Voltage - Forward (Vf) (Max) @ If |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ACDBC560-HFDIODE SCHOTTKY 60V 5A DO214AB |
2,406 | 0.25 |
RFQ |
Datasheet |
Tape & Reel (TR) | Automotive, AEC-Q101 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 210pF @ 4V, 1MHz | - | 500 µA @ 60 V | 60 V | 5A (DC) | -55°C ~ 125°C | 700 mV @ 5 A |
|
CDBW0520L-HFDIODE SCHOTTKY 20V 500MA SOD123 |
3,511 | 0.09 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | - | - | 250 µA @ 20 V | 20 V | 500mA | 125°C (Max) | 385 mV @ 500 mA | |
|
SS24B-HFDIODE SCHOTTKY 2A 40V SMB |
2,992 | 0.09 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 220pF @ 4V, 1MHz | - | 500 µA @ 40 V | 40 V | 2A | -55°C ~ 125°C | 550 mV @ 2 A | |
|
|
SS26B-HFDIODE SCHOTTKY 2A 60V SMB |
3,250 | 0.09 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 220pF @ 4V, 1MHz | - | 500 µA @ 60 V | 60 V | 2A | -55°C ~ 125°C | 700 mV @ 2 A | |
|
|
SB520E-GDIODE SCHOTTKY 20V 5A DO201AD |
2,719 | 0.32 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Through Hole | 500pF @ 4V, 1MHz | - | 500 µA @ 20 V | 20 V | 5A | -65°C ~ 125°C | 550 mV @ 5 A | |
|
|
S1Y-HFRECTIFIER GEN PURP 2000V 1A SMA |
3,031 | 0.11 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | - | 5 µA @ 2000 V | 2000 V | 1A | -65°C ~ 150°C | 1.1 V @ 1 A | |
|
|
SS315BF-HFDIODE SCHOTTKY 3A 150V SMBF |
3,291 | 0.11 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 400pF @ 4V, 1MHz | - | 300 µA @ 150 V | 150 V | 3A | -55°C ~ 150°C | 950 mV @ 3 A | |
|
|
SS320BF-HFDIODE SCHOTTKY 3A 200V SMBF |
3,252 | 0.11 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 400pF @ 4V, 1MHz | - | 300 µA @ 200 V | 200 V | 3A | -55°C ~ 150°C | 950 mV @ 3 A | |
|
|
SS310B-HFDIODE SCHOTTKY 3A 100V SMB |
3,934 | 0.11 |
RFQ |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 400pF @ 4V, 1MHz | - | 300 µA @ 100 V | 100 V | 3A | -55°C ~ 150°C | 850 mV @ 3 A | ||
|
CDBFR0540DIODE SCHOTTKY 40V 500MA 1005 |
3,785 | 0.11 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 170pF @ 0V, 1MHz | 22 ns | 20 µA @ 40 V | 40 V | 500mA | 125°C (Max) | 640 mV @ 1 A | |
|
|
CDBVFHT240-HFDIODE SCHOTTKY 40V 2A SOD-323ST |
2,292 | 0.11 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | - | - | 100 µA @ 40 V | 40 V | 2A | -55°C ~ 150°C | 500 mV @ 2 A | |
|
|
CDBFR0540-HFDIODE SCHOTTKY 40V 500MA 1005 |
3,843 | 0.11 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Last Time Buy | Surface Mount | 170pF @ 0V, 1MHz | 22 ns | 20 µA @ 40 V | 40 V | 500mA | 125°C | 510 mV @ 500 mA | |
|
|
ACDBMT1150-HFDIODE SCHOTTKY 150V 1A SOD123H |
3,417 | 0.14 |
RFQ |
Datasheet |
Tape & Reel (TR) | Automotive, AEC-Q101 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 120pF @ 4V, 1MHz | - | 500 µA @ 150 V | 150 V | 1A | -55°C ~ 150°C | - |
|
|
CGRB301-GDIODE GEN PURP 50V 3A DO214AA |
3,366 | 0.14 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | - | 5 µA @ 50 V | 50 V | 3A | 150°C (Max) | 1.1 V @ 3 A | |
|
CFRM105-HFDIODE GEN PURP 600V 1A MINISMA |
2,279 | 0.14 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 15pF @ 4V, 1MHz | 250 ns | 5 µA @ 600 V | 600 V | 1A (DC) | -55°C ~ 150°C | 1.3 V @ 1 A | |
|
CDBB340-GDIODE SCHOTTKY 40V 3A DO214AA |
3,305 | 0.14 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Not For New Designs | Surface Mount | - | - | 500 µA @ 40 V | 40 V | 3A | 125°C (Max) | 500 mV @ 3 A | |
|
CFRMT104-HFDIODE GEN PURP 400V 1A SOD123H |
2,006 | 0.14 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 250 ns | 5 µA @ 400 V | 400 V | 1A | -55°C ~ 150°C | 1.3 V @ 1 A | |
|
|
CDBB1200LR-HFDIODE SCHOTTKY 200V 1A DO214AA |
2,033 | 0.14 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 120pF @ 4V, 1MHz | - | 500 µA @ 200 V | 200 V | 1A | -50°C ~ 175°C | 850 mV @ 1 A | |
|
|
RS3BC-HFRECTIFIER FAST RECOVERY 100V 3A |
2,583 | 0.14 |
RFQ |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 40pF @ 4V, 1MHz | 150 ns | 5 µA @ 100 V | 100 V | 3A | -55°C ~ 150°C | 1.3 V @ 3 A | ||
|
|
RS3AC-HFRECTIFIER FAST RECOVERY 50V 3A S |
2,776 | 0.14 |
RFQ |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 40pF @ 4V, 1MHz | 150 ns | 5 µA @ 50 V | 50 V | 3A | -55°C ~ 150°C | 1.3 V @ 3 A |
