Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	RoHS	Speed	Diode Type	Part Status	Mounting Type	Capacitance @ Vr, F	Reverse Recovery Time (trr)	Current - Reverse Leakage @ Vr	Voltage - DC Reverse (Vr) (Max)	Current - Average Rectified (Io)	Operating Temperature	Voltage - Forward (Vf) (Max) @ If
BAS316,135 DIODE GEN PURP 100V 250MA SOD323 Nexperia USA Inc.	3,911	0.15	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT),Bulk	Automotive, AEC-Q101, BAS16	RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Standard	Active	Surface Mount	1.5pF @ 0V, 1MHz	4 ns	500 nA @ 80 V	100 V	250mA (DC)	150°C (Max)	1.25 V @ 150 mA
BAS21,235 DIODE GEN PURP 200V 200MA SOT23 Nexperia USA Inc.	2,411	0.15	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)		RoHS	Small Signal =< 200mA (Io), Any Speed	Standard	Active	Surface Mount	5pF @ 0V, 1MHz	50 ns	100 nA @ 200 V	200 V	200mA (DC)	150°C (Max)	1.25 V @ 200 mA
PMEG2010AEBF DIODE SCHOTTKY 20V 1A SOD523 Nexperia USA Inc.	3,062	0.41	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)		RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Schottky	Active	Surface Mount	19pF @ 1V, 1MHz	-	1.5 mA @ 20 V	20 V	1A (DC)	150°C (Max)	620 mV @ 1 A
PMEG4005EH,115 DIODE SCHOTTKY 40V 500MA SOD123F Nexperia USA Inc.	2,738	0.42	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)		RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Schottky	Active	Surface Mount	50pF @ 1V, 1MHz	-	100 µA @ 40 V	40 V	500mA (DC)	150°C (Max)	470 mV @ 500 mA
BAS16GWJ DIODE GEN PURP 100V 215MA SOD123 Nexperia USA Inc.	2,101	0.18	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT),Bulk	Automotive, AEC-Q101, BAS16	RoHS	Small Signal =< 200mA (Io), Any Speed	Standard	Active	Surface Mount	1.5pF @ 0V, 1MHz	4 ns	500 nA @ 80 V	100 V	215mA (DC)	150°C (Max)	1.25 V @ 150 mA
PMEG100T20ELRX PMEG100T20ELR/SOD123W/SOD2 Nexperia USA Inc.	2,593	0.45	RFQ		Tape & Reel (TR),Cut Tape (CT)		RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Schottky	Active	Surface Mount	200pF @ 1V, 1MHz	12 ns	1.25 µA @ 100 V	100 V	2A	175°C	800 mV @ 2 A
BAS316Z DIODE GEN PURP 100V 250MA SC76-2 Nexperia USA Inc.	2,011	0.15	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	Automotive, AEC-Q101, BAS16	RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Standard	Active	Surface Mount	1.5pF @ 0V, 1MHz	4 ns	500 nA @ 80 V	100 V	250mA (DC)	150°C (Max)	1.25 V @ 150 mA
1PS79SB40,699 DIODE SCHOTTKY 40V 120MA SOD523 Nexperia USA Inc.	3,048	0.07	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)		RoHS	Small Signal =< 200mA (Io), Any Speed	Schottky	Not For New Designs	Surface Mount	5pF @ 0V, 1MHz	-	10 µA @ 40 V	40 V	120mA (DC)	150°C (Max)	1 V @ 40 mA
PMEG6020ETR,115 DIODE SCHOTTKY 60V 2A CFP3 Nexperia USA Inc.	3,204	0.49	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT),Bulk		RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Schottky	Active	Surface Mount	240pF @ 1V, 1MHz	8.5 ns	150 µA @ 60 V	60 V	2A	175°C (Max)	530 mV @ 2 A
1PS79SB40,115 DIODE SCHOTTKY 40V 120MA SOD523 Nexperia USA Inc.	2,775	0.42	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)		RoHS	Small Signal =< 200mA (Io), Any Speed	Schottky	Active	Surface Mount	5pF @ 0V, 1MHz	-	10 µA @ 40 V	40 V	120mA (DC)	150°C (Max)	1 V @ 40 mA
PMEG4020ETR,115 DIODE SCHOTTKY 40V 2A SOD123W Nexperia USA Inc.	3,241	0.49	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)		RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Schottky	Active	Surface Mount	95pF @ 10V, 1MHz	-	100 µA @ 40 V	40 V	2A	175°C (Max)	490 mV @ 2 A
1PS79SB70,115 DIODE SCHOTTKY 70V 70MA SOD523 Nexperia USA Inc.	3,677	0.42	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT),Bulk		RoHS	Small Signal =< 200mA (Io), Any Speed	Schottky	Active	Surface Mount	2pF @ 0V, 1MHz	-	10 µA @ 70 V	70 V	70mA (DC)	150°C (Max)	1 V @ 15 mA
BAT54GWJ DIODE SCHOTTKY 30V 200MA SOD123 Nexperia USA Inc.	2,220	0.19	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	Automotive, AEC-Q101	RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Schottky	Active	Surface Mount	10pF @ 1V, 1MHz	-	2 µA @ 25 V	30 V	200mA (DC)	150°C (Max)	400 mV @ 10 mA
BAS20,215 DIODE GEN PURP 150V 200MA SOT23 Nexperia USA Inc.	926	0.16	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)		RoHS	Small Signal =< 200mA (Io), Any Speed	Standard	Active	Surface Mount	5pF @ 0V, 1MHz	50 ns	100 nA @ 150 V	150 V	200mA (DC)	150°C (Max)	1.25 V @ 200 mA
BAS20,235 DIODE GEN PURP 150V 200MA SOT23 Nexperia USA Inc.	3,382	0.02	RFQ	Datasheet	Tape & Reel (TR)		RoHS	Small Signal =< 200mA (Io), Any Speed	Standard	Active	Surface Mount	5pF @ 0V, 1MHz	50 ns	100 nA @ 150 V	150 V	200mA (DC)	150°C (Max)	1.25 V @ 200 mA
PMEG2005EB,115 DIODE SCHOTTKY 20V 500MA SOD523 Nexperia USA Inc.	3,127	0.38	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)		RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Schottky	Active	Surface Mount	30pF @ 1V, 1MHz	-	30 µA @ 10 V	20 V	500mA (DC)	125°C (Max)	480 mV @ 500 mA
PMEG045V150EPDZ DIODE SCHOTTKY 45V 15A CFP15 Nexperia USA Inc.	3,220	1.00	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	Automotive, AEC-Q101	RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Schottky	Active	Surface Mount	610pF @ 10V, 1MHz	19 ns	900 µA @ 45 V	45 V	15A	175°C (Max)	490 mV @ 15 A
PMEG050T150EPDZ DIODE SCHOTTKY 50V 15A CFP15 Nexperia USA Inc.	2,083	1.00	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	Automotive, AEC-Q101	RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Schottky	Active	Surface Mount	800pF @ 10V, 1MHz	60 ns	100 µA @ 50 V	50 V	15A	175°C (Max)	550 mV @ 15 A
PMEG2005EH,115 DIODE SCHOTTKY 20V 500MA SOD123F Nexperia USA Inc.	152,000	0.43	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT),Bulk		RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Schottky	Active	Surface Mount	80pF @ 1V, 1MHz	-	200 µA @ 20 V	20 V	500mA (DC)	150°C (Max)	390 mV @ 500 mA
PMEG6010AESBYL DIODE SCHOTTKY 60V 1A DSN1006-2 Nexperia USA Inc.	727	0.42	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)		RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Schottky	Active	Surface Mount	20pF @ 10V, 1MHz	2.4 ns	650 µA @ 60 V	60 V	1A	150°C (Max)	625 mV @ 1 A
