| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | RoHS | Speed | Diode Type | Part Status | Mounting Type | Capacitance @ Vr, F | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Operating Temperature | Voltage - Forward (Vf) (Max) @ If |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SB250TADIODE SCHOTTKY 50V 2A DO15 |
3,132 | 0.07 |
RFQ |
Datasheet |
Tape & Box (TB) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Through Hole | 140pF @ 4V, 1MHz | - | 5 mA @ 50 V | 50 V | 2A | -65°C ~ 150°C | 700 mV @ 2 A | |
.jpg)
|
DSS210TR2A, 100V, SOD-123FL, SCHOTTKY |
2,227 | 0.42 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 40pF @ 4V, 1MHz | - | 500 µA @ 100 V | 100 V | 2A | -55°C ~ 150°C | 850 mV @ 2 A | |
|
MBR120HWTRDIODE SCHOTTKY 20V 1A SOD123 |
3,403 | 0.07 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 50pF @ 4V, 1MHz | - | 400 µA @ 20 V | 20 V | 1A (DC) | -65°C ~ 125°C | 450 mV @ 1 A | |
|
|
FR201GTADIODE GPP 50V 2A DO15 |
3,875 | 0.07 |
RFQ |
Datasheet |
Tape & Box (TB) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 40pF @ 4V, 1MHz | 150 ns | 5 µA @ 35 V | 50 V | 2A | -55°C ~ 150°C | 1.3 V @ 2 A | |
|
|
FR202GTADIODE GPP 100V 2A DO15 |
2,491 | 0.07 |
RFQ |
Datasheet |
Tape & Box (TB) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 40pF @ 4V, 1MHz | 150 ns | 5 µA @ 70 V | 100 V | 2A | -55°C ~ 150°C | 1.3 V @ 2 A | |
|
|
FR203GTADIODE GPP 200V 2A DO15 |
3,500 | 0.07 |
RFQ |
Datasheet |
Tape & Box (TB) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 40pF @ 4V, 1MHz | 150 ns | 5 µA @ 140 V | 200 V | 2A | -55°C ~ 150°C | 1.3 V @ 2 A | |
|
|
FR204GTADIODE GPP 400V 2A DO15 |
3,760 | 0.07 |
RFQ |
Datasheet |
Tape & Box (TB) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 40pF @ 4V, 1MHz | 150 ns | 5 µA @ 280 V | 400 V | 2A | -55°C ~ 150°C | 1.3 V @ 2 A | |
|
|
FR205GTADIODE GPP 600V 2A DO15 |
2,609 | 0.07 |
RFQ |
Datasheet |
Tape & Box (TB) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 40pF @ 4V, 1MHz | 250 ns | 5 µA @ 420 V | 600 V | 2A | -55°C ~ 150°C | 1.3 V @ 2 A | |
|
|
FR206GTADIODE GPP 800V 2A DO15 |
2,429 | 0.07 |
RFQ |
Datasheet |
Tape & Box (TB) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Through Hole | 40pF @ 4V, 1MHz | 500 ns | 5 µA @ 560 V | 800 V | 2A | -55°C ~ 150°C | 1.3 V @ 2 A | |
|
SK220TRDIODE SCHOTTKY 200V 2A SMB |
2,341 | 0.07 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 170pF @ 5V, 1MHz | - | 1 mA @ 200 V | 200 V | 2A | -55°C ~ 150°C | 900 mV @ 2 A | |
|
ES2ETRDIODE GEN PURP 300V 2A SMA |
3,904 | 0.06 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 25pF @ 4V, 1MHz | 35 ns | 5 µA @ 300 V | 300 V | 2A | -55°C ~ 150°C | 1.25 V @ 2 A | |
|
|
FR207GTADIODE GPP 1KV 2A DO15 |
2,298 | 0.08 |
RFQ |
Datasheet |
Tape & Box (TB) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Through Hole | 40pF @ 4V, 1MHz | 500 ns | 5 µA @ 700 V | 1000 V | 2A | -55°C ~ 150°C | 1.3 V @ 2 A | |
|
S5ACTRDIODE GEN PURP 50V 5A SMC |
2,997 | 0.10 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | 40pF @ 4V, 1MHz | - | 10 µA @ 50 V | 50 V | 5A | -65°C ~ 150°C | 1.15 V @ 5 A | |
|
|
S5BCTRDIODE GEN PURP 100V 5A SMC |
2,573 | 0.10 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | 40pF @ 4V, 1MHz | - | 10 µA @ 100 V | 100 V | 5A | -65°C ~ 150°C | 1.15 V @ 5 A | |
|
|
S5DCTRDIODE GEN PURP 200V 5A SMC |
2,231 | 0.10 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | 40pF @ 4V, 1MHz | - | 10 µA @ 200 V | 200 V | 5A | -65°C ~ 150°C | 1.15 V @ 5 A | |
|
|
S5GCTRDIODE GEN PURP 400V 5A SMC |
2,065 | 0.10 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | 40pF @ 4V, 1MHz | - | 10 µA @ 400 V | 400 V | 5A | -65°C ~ 150°C | 1.15 V @ 5 A | |
|
|
S5JCTRDIODE GEN PURP 600V 5A SMC |
2,857 | 0.10 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | 40pF @ 4V, 1MHz | - | 10 µA @ 600 V | 600 V | 5A | -65°C ~ 150°C | 1.15 V @ 5 A | |
|
|
S5KCTRDIODE GEN PURP 800V 5A SMC |
3,432 | 0.10 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | 40pF @ 4V, 1MHz | - | 10 µA @ 800 V | 800 V | 5A | -65°C ~ 150°C | 1.15 V @ 5 A | |
|
|
S5MCTRDIODE GEN PURP 1KV 5A SMC |
2,011 | 0.10 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | 40pF @ 4V, 1MHz | - | 10 µA @ 1000 V | 1000 V | 5A | -65°C ~ 150°C | 1.15 V @ 5 A | |
|
11DQ04TADIODE SCHOTTKY 40V 1.1A DO-41 |
3,183 | 0.02 |
RFQ |
Datasheet |
Tape & Box (TB) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Through Hole | 55pF @ 5V, 1MHz | - | 1 mA @ 40 V | 40 V | 1.1A | -40°C ~ 150°C | 550 mV @ 1 A |
