| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Packaging | Series | ProductStatus | Type | Material-Core | Inductance | Tolerance | CurrentRating(Amps) | Current-Saturation(Isat) | Shielding | DCResistance(DCR) | Q@Freq | Frequency-SelfResonant | Ratings | OperatingTemperature | InductanceFrequency-Test | Features | MountingType | Size/Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
47150SCFIXED IND 15UH 3.2A 46.5MOHM SMD |
2,596 | 0.00 |
RFQ |
Datasheet |
Nonstandard, 4 Lead | Tape & Reel (TR) | 4700S | Obsolete | Wirewound | - | 15 µH | ±20% | 3.2 A | - | Shielded | 46.5mOhm Max | 29 @ 1MHz | 18MHz | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - |
|
|
47151SCFIXED IND 150UH 1.1A 410MOHM SMD |
2,562 | 0.00 |
RFQ |
Datasheet |
Nonstandard, 4 Lead | Tape & Reel (TR) | 4700S | Obsolete | Wirewound | - | 150 µH | ±20% | 1.1 A | - | Shielded | 410mOhm Max | 19 @ 800kHz | 7MHz | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - |
|
|
471R0SCFIXED IND 1UH 10A 4.8 MOHM SMD |
3,023 | 0.00 |
RFQ |
Datasheet |
Nonstandard, 4 Lead | Tape & Reel (TR) | 4700S | Obsolete | Wirewound | - | 1 µH | ±30% | 10 A | - | Shielded | 4.8mOhm Max | 24 @ 1MHz | 79MHz | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - |
|
|
472R2SCFIXED IND 2.2UH 7A 8.5 MOHM SMD |
3,428 | 0.00 |
RFQ |
Datasheet |
Nonstandard, 4 Lead | Tape & Reel (TR) | 4700S | Obsolete | Wirewound | - | 2.2 µH | ±30% | 7 A | - | Shielded | 8.5mOhm Max | 24 @ 1MHz | 44MHz | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - |
|
|
47331SCFIXED IND 330UH 700MA 940MOHM SM |
2,073 | 0.00 |
RFQ |
Datasheet |
Nonstandard, 4 Lead | Tape & Reel (TR) | 4700S | Obsolete | Wirewound | - | 330 µH | ±20% | 700 mA | - | Shielded | 940mOhm Max | 21 @ 800kHz | 5MHz | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - |
|
|
473R3SCFIXED IND 3.3UH 6.4A 11.1MOHM SM |
2,082 | 0.00 |
RFQ |
Datasheet |
Nonstandard, 4 Lead | Tape & Reel (TR) | 4700S | Obsolete | Wirewound | - | 3.3 µH | ±30% | 6.4 A | - | Shielded | 11.1mOhm Max | 25 @ 1MHz | 36MHz | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - |
|
|
47471SCFIXED IND 470UH 580MA 1.33OHM SM |
2,188 | 0.00 |
RFQ |
Datasheet |
Nonstandard, 4 Lead | Tape & Reel (TR) | 4700S | Obsolete | Wirewound | - | 470 µH | ±20% | 580 mA | - | Shielded | 1.33Ohm Max | 23 @ 800kHz | 5MHz | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - |
|
|
474R7SCFIXED IND 4.7UH 5.8A 16.4MOHM SM |
2,694 | 0.00 |
RFQ |
Datasheet |
Nonstandard, 4 Lead | Tape & Reel (TR) | 4700S | Obsolete | Wirewound | - | 4.7 µH | ±30% | 5.8 A | - | Shielded | 16.4mOhm Max | 25 @ 1MHz | 34MHz | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - |
|
|
47680SCFIXED IND 68UH 1.6A 210MOHM SMD |
2,908 | 0.00 |
RFQ |
Datasheet |
Nonstandard, 4 Lead | Tape & Reel (TR) | 4700S | Obsolete | Wirewound | - | 68 µH | ±20% | 1.6 A | - | Shielded | 210mOhm Max | 23 @ 1MHz | 9MHz | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - |
|
80302CFIXED IND 150UH 1A 140 MOHM TH |
2,457 | 0.00 |
RFQ |
Datasheet |
Radial, Horizontal, Corner Terminals | Tube | 803 | Obsolete | Toroidal | - | 150 µH | ±10% | 1 A | - | Unshielded | 140mOhm Max | - | - | - | 0°C ~ 70°C | - | - | Through Hole | - |
|
|
80304CFIXED IND 150UH 3.5A 90 MOHM TH |
3,559 | 0.00 |
RFQ |
Datasheet |
Radial, Horizontal, Corner Terminals | Tube | 803 | Obsolete | Toroidal | - | 150 µH | ±10% | 3.5 A | - | Unshielded | 90mOhm Max | - | - | - | 0°C ~ 70°C | - | - | Through Hole | - |
|
|
80306CFIXED IND 220UH 3A 100 MOHM TH |
2,427 | 0.00 |
RFQ |
Datasheet |
Radial, Horizontal, Corner Terminals | Tube | 803 | Obsolete | Toroidal | - | 220 µH | ±10% | 3 A | - | Unshielded | 100mOhm Max | - | - | - | 0°C ~ 70°C | - | - | Through Hole | - |
|
28222CFIXED IND 2.2UH 11.2A 4.4MOHM SM |
3,259 | 0.00 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | 2800 | Obsolete | Wirewound | - | 2.2 µH | - | 11.2 A | - | Unshielded | 4.4mOhm Max | 36.9 @ 1MHz | 58MHz | - | -40°C ~ 125°C | 10 kHz | - | Surface Mount | - |
|
|
28224CFIXED IND 220UH 1.2A 381MOHM SMD |
2,247 | 0.00 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | 2800 | Obsolete | Wirewound | - | 220 µH | - | 1.2 A | - | Unshielded | 381mOhm Max | 18 @ 800kHz | 5.8MHz | - | -40°C ~ 125°C | 10 kHz | - | Surface Mount | - |
|
|
28225CFIXED IND 2.2MH 350MA 3.72OHM SM |
3,455 | 0.00 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | 2800 | Obsolete | Wirewound | - | 2.2 mH | - | 350 mA | - | Unshielded | 3.72Ohm Max | 15.8 @ 800kHz | 3.3MHz | - | -40°C ~ 125°C | 10 kHz | - | Surface Mount | - |
|
|
28335CFIXED IND 3.3MH 290MA 5.76OHM SM |
2,536 | 0.00 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | 2800 | Obsolete | Wirewound | - | 3.3 mH | - | 290 mA | - | Unshielded | 5.76Ohm Max | 12.8 @ 800kHz | 3.2MHz | - | -40°C ~ 125°C | 10 kHz | - | Surface Mount | - |
|
|
47101SCFIXED IND 100UH 1.3A 267MOHM SMD |
2,314 | 0.00 |
RFQ |
Datasheet |
Nonstandard, 4 Lead | Tape & Reel (TR),Cut Tape (CT) | 4700S | Obsolete | Wirewound | - | 100 µH | ±20% | 1.3 A | - | Shielded | 267mOhm Max | 20 @ 800kHz | 8MHz | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - |
|
|
47330SCFIXED IND 33UH 2.2A 91.1MOHM SMD |
3,963 | 0.00 |
RFQ |
Datasheet |
Nonstandard, 4 Lead | Tape & Reel (TR),Cut Tape (CT) | 4700S | Obsolete | Wirewound | - | 33 µH | ±20% | 2.2 A | - | Shielded | 91.1mOhm Max | 23 @ 1MHz | 13MHz | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - |
|
|
47470SCFIXED IND 47UH 1.9A 168MOHM SMD |
2,873 | 0.00 |
RFQ |
Datasheet |
Nonstandard, 4 Lead | Tape & Reel (TR),Cut Tape (CT) | 4700S | Obsolete | Wirewound | - | 47 µH | ±20% | 1.9 A | - | Shielded | 168mOhm Max | 23 @ 1MHz | 11MHz | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - |
|
|
47681SCFIXED IND 680UH 480MA 1.78OHM SM |
2,477 | 0.00 |
RFQ |
Datasheet |
Nonstandard, 4 Lead | Tape & Reel (TR),Cut Tape (CT) | 4700S | Obsolete | Wirewound | - | 680 µH | ±20% | 480 mA | - | Shielded | 1.78Ohm Max | 17 @ 800kHz | 4MHz | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - |
