| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | NumberofChannels | Voltage-Isolation | CurrentTransferRatio(Min) | CurrentTransferRatio(Max) | TurnOn/TurnOffTime(Typ) | Rise/FallTime(Typ) | InputType | OutputType | Voltage-Output(Max) | Current-Output/Channel | Voltage-Forward(Vf)(Typ) | Current-DCForward(If)(Max) | VceSaturation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PC4N360YSZXOPTOISO 2.5KV DARL W/BASE 6DIP |
2,584 | 0.00 |
RFQ |
Tube | - | Obsolete | 1 | 2500Vrms | 100% @ 10mA | - | - | - | DC | Darlington with Base | 30V | 100mA | - | - | 300mV | - | Through Hole | |
|
|
PC4N370NSZXOPTOISO 1.5KV DARL W/BASE 6DIP |
2,006 | 0.00 |
RFQ |
Tube | - | Obsolete | 1 | 1500Vrms | 100% @ 10mA | - | - | - | DC | Darlington with Base | 30V | 100mA | - | - | 300mV | - | Through Hole | |
|
|
PC4N370YSZXOPTOISO 1.5KV DARL W/BASE 6DIP |
2,279 | 0.00 |
RFQ |
Tube | - | Obsolete | 1 | 1500Vrms | 100% @ 10mA | - | - | - | DC | Darlington with Base | 30V | 100mA | - | - | 300mV | - | Through Hole | |
|
PC6N139XOPTOISO 2.5KV DARL W/BASE 8-DIP |
3,377 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 2500Vrms | 400% @ 500µA | - | 300ns, 1.5µs | - | DC | Darlington with Base | 18V | 60mA | 1.5V | 20 mA | - | 0°C ~ 70°C | Through Hole |
|
PC81713NIPOPTOISOLATOR 5KV TRANS 4SMD |
2,048 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Obsolete | 1 | 5000Vrms | 200% @ 500µA | 500% @ 500µA | - | 4µs, 3µs | DC | Transistor | 80V | 50mA | 1.2V | 10 mA | 200mV | -30°C ~ 100°C | Surface Mount |
|
|
PC81712NIPOPTOISOLATOR 5KV TRANS 4SMD |
2,108 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Obsolete | 1 | 5000Vrms | 160% @ 500µA | 400% @ 500µA | - | 4µs, 3µs | DC | Transistor | 80V | 50mA | 1.2V | 10 mA | 200mV | -30°C ~ 100°C | Surface Mount |
|
PC3Q410NIPOPTOISO 2.5KV 4CH TRANS 16SOIC |
2,395 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Obsolete | 4 | 2500Vrms | 50% @ 500µA | 400% @ 500µA | - | 4µs, 3µs | AC, DC | Transistor | 80V | 50mA | 1.2V | 10 mA | 200mV | -30°C ~ 100°C | Surface Mount |
|
|
PC81710NIPOPTOISOLATOR 5KV TRANS 4SMD |
3,653 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Obsolete | 1 | 5000Vrms | 100% @ 500µA | 600% @ 500µA | - | 4µs, 3µs | DC | Transistor | 80V | 50mA | 1.2V | 10 mA | 200mV | -30°C ~ 100°C | Surface Mount |
|
PC817X7J000FOPTOISOLATOR 5KV TRANS 4DIP |
2,459 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5000Vrms | 50% @ 5mA | 600% @ 5mA | - | 4µs, 3µs | DC | Transistor | 80V | 50mA | 1.2V | 50 mA | 200mV | -30°C ~ 100°C | Through Hole |
|
PC851XJ0000FOPTOISOLATOR 5KV TRANS 4DIP |
3,589 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5000Vrms | - | - | - | 4µs, 5µs | DC | Transistor | 350V | 50mA | 1.2V | 50 mA | 300mV | -25°C ~ 100°C | Through Hole |
|
|
PC852XJ0000FOPTOISOLATOR 5KV DARL 4DIP |
2,569 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5000Vrms | 1000% @ 1mA | - | - | 100µs, 20µs | DC | Darlington | 350V | 150mA | 1.2V | 50 mA | 1.2V | -30°C ~ 100°C | Through Hole |
|
|
PC814XP1J00FOPTOISOLATOR 5KV TRANS 4SMD |
2,078 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Obsolete | 1 | 5000Vrms | 100% @ 1mA | 150% @ 1mA | - | 4µs, 3µs | AC, DC | Transistor | 80V | 50mA | 1.2V | 50 mA | 200mV | -30°C ~ 100°C | Surface Mount |
|
PC957L0NSZ0FOPTOISOLTR 5KV TRANSISTOR 8-DIP |
3,687 | 0.00 |
RFQ |
Datasheet |
Tube | OPIC™ | Obsolete | 1 | 5000Vrms | 19% @ 16mA | 50% @ 16mA | 200ns, 400ns | - | DC | Transistor | 20V | 8mA | 1.7V | 25 mA | - | -55°C ~ 85°C | Through Hole |
|
|
PC81712NSZ0FOPTOISOLATOR 5KV TRANS 4DIP |
2,889 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5000Vrms | 160% @ 500µA | 400% @ 500µA | - | 4µs, 3µs | DC | Transistor | 80V | 50mA | 1.2V | 10 mA | 200mV | -30°C ~ 100°C | Through Hole |
|
|
PC817X0J000FOPTOISOLATOR 5KV TRANS 4DIP |
3,385 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5000Vrms | 80% @ 5mA | 600% @ 5mA | - | 4µs, 3µs | DC | Transistor | 80V | 50mA | 1.2V | 50 mA | 200mV | -30°C ~ 100°C | Through Hole |
|
|
PC81713NSZ0FOPTOISOLATOR 5KV TRANS 4DIP |
2,259 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5000Vrms | 200% @ 500µA | 500% @ 500µA | - | 4µs, 3µs | DC | Transistor | 80V | 50mA | 1.2V | 10 mA | 200mV | -30°C ~ 100°C | Through Hole |
|
|
PC817X1J000FOPTOISOLATOR 5KV TRANS 4DIP |
3,141 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5000Vrms | 80% @ 5mA | 160% @ 5mA | - | 4µs, 3µs | DC | Transistor | 80V | 50mA | 1.2V | 50 mA | 200mV | -30°C ~ 100°C | Through Hole |
|
|
PC817X2J000FOPTOISOLATOR 5KV TRANS 4DIP |
2,926 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5000Vrms | 130% @ 5mA | 230% @ 5mA | - | 4µs, 3µs | DC | Transistor | 80V | 50mA | 1.2V | 50 mA | 200mV | -30°C ~ 100°C | Through Hole |
|
|
PC81711NSZ0FOPTOISOLATOR 5KV TRANS 4DIP |
3,209 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5000Vrms | 120% @ 500µA | 300% @ 500µA | - | 4µs, 3µs | DC | Transistor | 80V | 50mA | 1.2V | 10 mA | 200mV | -30°C ~ 100°C | Through Hole |
|
|
PC81710NSZ0FOPTOISOLATOR 5KV TRANS 4DIP |
3,268 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5000Vrms | 100% @ 500µA | 600% @ 500µA | - | 4µs, 3µs | DC | Transistor | 80V | 50mA | 1.2V | 10 mA | 200mV | -30°C ~ 100°C | Through Hole |
