Optoisolators - Transistor, Photovoltaic Output(11011)
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | NumberofChannels | Voltage-Isolation | CurrentTransferRatio(Min) | CurrentTransferRatio(Max) | TurnOn/TurnOffTime(Typ) | Rise/FallTime(Typ) | InputType | OutputType | Voltage-Output(Max) | Current-Output/Channel | Voltage-Forward(Vf)(Typ) | Current-DCForward(If)(Max) | VceSaturation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
FOD2742BTRANSISTOR OUTPUT OPTOCOUPLER, 2 |
2,921 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | 1 | 2500Vrms | 100% @ 10mA | 200% @ 10mA | - | - | DC | Transistor | 70V | 50mA | 1.2V | - | 400mV | -25°C ~ 85°C | Surface Mount |
|
FODM452R2VLOGIC IC OUTPUT OPTOCOUPLER |
2,766 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | 1 | 3750Vrms | 20% @ 16mA | 50% @ 16mA | 400ns, 350ns | - | DC | Transistor | 20V | 8mA | 1.6V | 25 mA | - | -40°C ~ 85°C | Surface Mount |
|
H11G1SR2VMDARLINGTON OUTPUT OPTOCOUPLER, 7 |
3,069 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | 1 | 4170Vrms | 1000% @ 10mA | - | 5µs, 100µs | - | DC | Darlington with Base | 100V | - | 1.3V | 60 mA | 1V | -40°C ~ 100°C | Surface Mount |
|
MOC8050VMDARLINGTON OUTPUT OPTOCOUPLER, 7 |
3,045 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | 1 | 4170Vrms | 500% @ 10mA | - | 8.5µs, 95µs | - | DC | Darlington | 80V | 150mA | 1.18V | 60 mA | - | -40°C ~ 100°C | Through Hole |
|
HCPL2530SMLOGIC IC OUTPUT OPTOCOUPLER, 2-E |
300 | 1.09 |
RFQ |
Datasheet |
Bulk | - | Active | 2 | 2500Vrms | 7% @ 16mA | 50% @ 16mA | 450ns, 300ns | - | DC | Transistor | 20V | 8mA | 1.45V | 25 mA | - | -55°C ~ 100°C | Surface Mount |
|
HCPL2531VMLOGIC IC OUTPUT OPTOCOUPLER, 2-E |
2,020 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | 2 | 5000Vrms | 19% @ 16mA | 50% @ 16mA | 250ns, 260ns | - | DC | Transistor | 20V | 8mA | 1.45V | 25 mA | - | -40°C ~ 100°C | Through Hole |
|
|
FOD2712AVTRANSISTOR OUTPUT OPTOCOUPLER, 2 |
2,962 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | 1 | 2500Vrms | 100% @ 10mA | 200% @ 10mA | - | - | DC | Transistor | 30V | 50mA | 1.5V (Max) | - | 400mV | -40°C ~ 85°C | Surface Mount |
|
MCT6WTRANSISTOR OUTPUT OPTOCOUPLER, 2 |
2,753 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | 2 | 5000Vrms | 20% @ 10mA | - | 2.4µs, 2.4µs | - | DC | Transistor | 30V | 30mA | 1.2V | 60 mA | 400mV | -55°C ~ 100°C | Through Hole |
|
JANTXV4N48OPTOISO 1KV TRANS W/BASE TO78-6 |
2,876 | 46.07 |
RFQ |
Datasheet |
Bulk | - | Active | 1 | 1000VDC | 100% @ 1mA | 500% @ 1mA | - | 20µs, 20µs (Max) | DC | Transistor with Base | 40V | 50mA | 1.5V (Max) | 40 mA | 300mV | -55°C ~ 125°C | Through Hole |
|
|
JANTXV4N49OPTOISO 1KV TRANS W/BASE TO78-6 |
2,123 | 46.07 |
RFQ |
Datasheet |
Bulk | - | Active | 1 | 1000VDC | 200% @ 1mA | 1000% @ 1mA | - | 20µs, 20µs (Max) | DC | Transistor with Base | 40V | 50mA | 1.5V (Max) | 40 mA | 300mV | -55°C ~ 125°C | Through Hole |
|
8421060000OPTOISOLATOR TRANS MODULE |
3,985 | 48.19 |
RFQ |
Datasheet |
Bulk | - | Active | 1 | - | - | - | - | - | DC | Transistor | 48V | 50mA | - | - | - | -25°C ~ 40°C | DIN Rail |
|
|
8421380000OPTOISOLATOR TRANS MODULE |
3,557 | 51.81 |
RFQ |
Datasheet |
Bulk | - | Active | 1 | - | - | - | - | - | DC | Transistor | 48V | 20mA | - | - | - | -25°C ~ 50°C | DIN Rail |
|
OPI153OPTOISOLTR 50KV DARLINGTON AXIAL |
3,829 | 55.01 |
RFQ |
Datasheet |
Bulk | - | Active | 1 | 50000VDC | 25% @ 20mA | - | 120µs, 70µs | - | DC | Darlington | 15V | 25mA | 1.3V | 50 mA | 1.2V | -40°C ~ 85°C | Through Hole |
|
|
HCPL-5500#100OPTOISO 1.5KV TRANS W/BASE 8SMD |
2,474 | 71.99 |
RFQ |
Datasheet |
Bulk | - | Active | 1 | 1500VDC | 9% @ 16mA | - | 400ns, 1µs | - | DC | Transistor with Base | 20V | 8mA | 1.55V | 20 mA | - | -55°C ~ 125°C | Surface Mount |
|
HCPL-5500#200OPTOISO 1.5KV TRANS W/BASE 8DIP |
2,883 | 71.99 |
RFQ |
Datasheet |
Bulk | - | Active | 1 | 1500VDC | 9% @ 16mA | - | 400ns, 1µs | - | DC | Transistor with Base | 20V | 8mA | 1.55V | 20 mA | - | -55°C ~ 125°C | Through Hole |
|
HCPL-5500#300OPTOISO 1.5KV TRANS W/BASE 8SMD |
2,994 | 73.21 |
RFQ |
Datasheet |
Bulk | - | Active | 1 | 1500VDC | 9% @ 16mA | - | 400ns, 1µs | - | DC | Transistor with Base | 20V | 8mA | 1.55V | 20 mA | - | -55°C ~ 125°C | Surface Mount |
|
HCC1002RADIATION CAPABLE OPTOISOLATOR 4 |
2,322 | 77.55 |
RFQ |
Datasheet |
Tray | - | Active | 1 | 1000VDC | - | - | - | 20µs, 20µs (Max) | DC | - | 40V | 50mA | 1.9V (Max) | 40 mA | 300mV | -55°C ~ 150°C | Surface Mount |
|
|
8287730000OPTOISOLATOR TRANS MODULE |
2,849 | 49.81 |
RFQ |
Datasheet |
Bulk,Bulk | - | Active | 1 | - | - | - | - | - | DC | Transistor | 24V | 2A | - | - | - | -25°C ~ 40°C | DIN Rail |
|
|
HCC1001RADIATION CAPABLE OPTOISOLATOR 6 |
2,626 | 80.49 |
RFQ |
Datasheet |
Tray | - | Active | 1 | 1000VDC | - | - | - | 20µs, 20µs (Max) | DC | - | 40V | 50mA | 1.9V (Max) | 40 mA | 300mV | -55°C ~ 150°C | Surface Mount |
|
|
HCPL-5501OPTOISO 1.5KV TRANS W/BASE 8DIP |
2,163 | 82.17 |
RFQ |
Datasheet |
Bulk | - | Active | 1 | 1500VDC | 9% @ 16mA | - | 400ns, 1µs | - | DC | Transistor with Base | 20V | 8mA | 1.55V | 20 mA | - | -55°C ~ 125°C | Through Hole |
