Mfr. Part #	Availability	Price	Quantity	Datasheet	Package/Case	Packaging	Series	ProductStatus	Type	Voltage-Max	Current-Max	Current-Hold(Ih)(Max)	Current-Trip(It)	TimetoTrip	Resistance-Initial(Ri)(Min)	Resistance-PostTrip(R1)(Max)	Resistance-25°C(Typ)	OperatingTemperature	Ratings	MountingType	Size/Dimension	Height-Seated(Max)	Thickness(Max)
MPTH250V080V PTC RESET FUSE 100V 0.08A RADIAL Meritek	2,802	0.50	RFQ	Datasheet	Radial, Disc	Bulk	MPTH	Active	Polymeric	100V	3 A	80 mA	160 mA	4 s	14 Ohms	33 Ohms	-	-40°C ~ 85°C	-	Through Hole	0.228 Dia x 0.181 T (5.80mm x 4.60mm)	0.378 (9.60mm)	-
MPTR30V900 PTC RESET FUSE 30V 9A RADIAL Meritek	3,185	0.50	RFQ	Datasheet	Radial, Disc	Bulk	MPTR	Active	Polymeric	30V	100 A	9 A	18 A	20 s	5 mOhms	20 mOhms	-	-40°C ~ 85°C	-	Through Hole	0.949 L x 0.118 W (24.10mm x 3.00mm)	1.169 (29.70mm)	-
MPTR16V700 PTC RESET FUSE 16V 7A RADIAL Meritek	2,168	0.51	RFQ	Datasheet	Radial, Disc	Bulk	MPTR	Active	Polymeric	16V	100 A	7 A	11.9 A	8 s	6 mOhms	21 mOhms	-	-40°C ~ 85°C	-	Through Hole	0.441 L x 0.118 W (11.20mm x 3.00mm)	0.776 (19.70mm)	-
MPTR16V450H PTC RESET FUSE 16V 4.5A RADIAL Meritek	3,287	0.51	RFQ	Datasheet	Radial, Disc	Bulk	MPTR	Active	Polymeric	16V	100 A	4.5 A	7.8 A	3 s	22 mOhms	54 mOhms	-	-40°C ~ 125°C	-	Through Hole	0.409 L x 0.118 W (10.40mm x 3.00mm)	0.614 (15.60mm)	-
MPRV120V185 PTC RESET FUSE 120V 1.85A RADIAL Meritek	3,929	0.51	RFQ	Datasheet	Radial, Disc	Bulk	MPRV	Active	Polymeric	120V	12 A	1.85 A	3.7 A	12.6 s	80 mOhms	190 mOhms	-	-40°C ~ 85°C	-	Through Hole	0.783 Dia x 0.161 T (19.90mm x 4.10mm)	0.980 (24.90mm)	-
MPTR16V700H PTC RESET FUSE 16V 7A RADIAL Meritek	3,786	0.52	RFQ	Datasheet	Radial, Disc	Bulk	MPTR	Active	Polymeric	16V	100 A	7 A	13 A	7 s	10 mOhms	25 mOhms	-	-40°C ~ 125°C	-	Through Hole	0.551 L x 0.118 W (14.00mm x 3.00mm)	0.862 (21.90mm)	-
MPTR16V600 PTC RESET FUSE 16V 6A RADIAL Meritek	3,142	0.53	RFQ	Datasheet	Radial, Disc	Bulk	MPTR	Active	Polymeric	16V	100 A	6 A	10.2 A	5.8 s	9 mOhms	33 mOhms	-	-40°C ~ 85°C	-	Through Hole	0.421 L x 0.118 W (10.70mm x 3.00mm)	0.673 (17.10mm)	-
MPRV120V200 PTC RESET FUSE 120V 2A RADIAL Meritek	2,351	0.55	RFQ	Datasheet	Radial, Disc	Bulk	MPRV	Active	Polymeric	120V	20 A	2 A	4.2 A	36 s	80 mOhms	210 mOhms	-	-40°C ~ 85°C	-	Through Hole	0.925 Dia x 0.161 T (23.50mm x 4.10mm)	1.098 (27.90mm)	-
MPTR30V600 PTC RESET FUSE 30V 6A RADIAL Meritek	2,329	0.55	RFQ	Datasheet	Radial, Disc	Bulk	MPTR	Active	Polymeric	30V	100 A	6 A	12 A	16 s	5 mOhms	40 mOhms	-	-40°C ~ 85°C	-	Through Hole	0.650 L x 0.118 W (16.50mm x 3.00mm)	0.980 (24.90mm)	-
MPTR16V650H PTC RESET FUSE 16V 6.5A RADIAL Meritek	2,593	0.55	RFQ	Datasheet	Radial, Disc	Bulk	MPTR	Active	Polymeric	16V	100 A	6.5 A	12 A	5.5 s	11 mOhms	26 mOhms	-	-40°C ~ 125°C	-	Through Hole	0.500 L x 0.118 W (12.70mm x 3.00mm)	0.874 (22.20mm)	-
MPTR16V300 PTC RESET FUSE 16V 3A RADIAL Meritek	3,976	0.55	RFQ	Datasheet	Radial, Disc	Bulk	MPTR	Active	Polymeric	16V	100 A	3 A	5.1 A	2 s	34 mOhms	105 mOhms	-	-40°C ~ 85°C	-	Through Hole	0.280 L x 0.118 W (7.10mm x 3.00mm)	0.433 (11.00mm)	-
MPTR16V800 PTC RESET FUSE 16V 8A RADIAL Meritek	2,103	0.56	RFQ	Datasheet	Radial, Disc	Bulk	MPTR	Active	Polymeric	16V	100 A	8 A	13.6 A	9 s	5 mOhms	18 mOhms	-	-40°C ~ 85°C	-	Through Hole	0.500 L x 0.118 W (12.70mm x 3.00mm)	0.823 (20.90mm)	-
MPTH600V160M PTC RESET FUSE 250V 0.16A RADIAL Meritek	2,588	0.56	RFQ	Datasheet	Radial, Disc	Bulk	MPTH	Active	Polymeric	250V	3 A	160 mA	320 mA	7 s	4 Ohms	16 Ohms	-	-40°C ~ 85°C	-	Through Hole	0.354 L x 0.181 W (9.00mm x 4.60mm)	0.492 (12.50mm)	-
MPRV240V150 PTC RESET FUSE 240V 1.5A RADIAL Meritek	2,630	0.56	RFQ	Datasheet	Radial, Disc	Bulk	MPRV	Active	Polymeric	240V	15 A	1.5 A	3 A	23 s	120 mOhms	320 mOhms	-	-40°C ~ 85°C	-	Through Hole	0.921 L x 0.209 W (23.40mm x 5.30mm)	1.217 (30.90mm)	-
MPRV240V200 PTC RESET FUSE 240V 2A RADIAL Meritek	3,385	0.56	RFQ	Datasheet	Radial, Disc	Bulk	MPRV	Active	Polymeric	240V	20 A	2 A	4 A	28 s	90 mOhms	220 mOhms	-	-40°C ~ 85°C	-	Through Hole	0.980 Dia x 0.240 T (24.90mm x 6.10mm)	1.331 (33.80mm)	-
MPRV120V250 PTC RESET FUSE 120V 2.5A RADIAL Meritek	3,036	0.56	RFQ	Datasheet	Radial, Disc	Bulk	MPRV	Active	Polymeric	120V	15 A	2.5 A	5 A	15.6 s	50 mOhms	130 mOhms	-	-40°C ~ 85°C	-	Through Hole	0.886 Dia x 0.161 T (22.50mm x 4.10mm)	1.083 (27.50mm)	-
MPTR16V500 PTC RESET FUSE 16V 5A RADIAL Meritek	3,023	0.57	RFQ	Datasheet	Radial, Disc	Bulk	MPTR	Active	Polymeric	16V	100 A	5 A	8.5 A	3.6 s	14 mOhms	44 mOhms	-	-40°C ~ 85°C	-	Through Hole	0.409 L x 0.118 W (10.40mm x 3.00mm)	0.980 (24.90mm)	-
MPTR30V800 PTC RESET FUSE 30V 8A RADIAL Meritek	2,007	0.59	RFQ	Datasheet	Radial, Disc	Bulk	MPTR	Active	Polymeric	30V	100 A	8 A	16 A	18.8 s	5 mOhms	20 mOhms	-	-40°C ~ 85°C	-	Through Hole	0.850 L x 0.118 W (21.60mm x 3.00mm)	1.150 (29.20mm)	-
MPTS2920L50016R PTC RESET FUSE 16V 5A 2920 Meritek	2,968	0.59	RFQ	Datasheet	2920 (7351 Metric), Concave	Tape & Reel (TR)	MPTS	Active	Polymeric	16V	100 A	5 A	10 A	5 s	5 mOhms	25 mOhms	-	-40°C ~ 85°C	-	Surface Mount	0.290 L x 0.202 W (7.36mm x 5.12mm)	-	0.059 (1.50mm)
MPTS2920L40016R PTC RESET FUSE 16V 4A 2920 Meritek	2,818	0.59	RFQ	Datasheet	2920 (7351 Metric), Concave	Tape & Reel (TR)	MPTS	Active	Polymeric	16V	100 A	4 A	8 A	4 s	10 mOhms	40 mOhms	-	-40°C ~ 85°C	-	Surface Mount	0.290 L x 0.202 W (7.36mm x 5.12mm)	-	0.059 (1.50mm)
