| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | FETType | FETFeature | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | InputCapacitance(Ciss)(Max)@Vds | Power-Max | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
IRF7309PBFP-CHANNEL POWER MOSFET |
2,934 | 1.00 |
RFQ |
Tube | HEXFET® | Obsolete | N and P-Channel | Standard | 30V | 4A (Ta), 3A (Ta) | 50mOhm @ 2.4A, 10V, 100mOhm @ 1.8A, 10V | 1V @ 250µA | 25nC @ 4.5V | 520pF, 440pF @ 15V | 1.4W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
IRF7314PBFP-CHANNEL POWER MOSFET |
2,214 | 1.00 |
RFQ |
Datasheet |
Tube | HEXFET® | Obsolete | 2 P-Channel (Dual) | Logic Level Gate | 20V | 5.3A | 58mOhm @ 2.9A, 4.5V | 700mV @ 250µA | 29nC @ 4.5V | 780pF @ 15V | 2W | -55°C ~ 150°C (TJ) | Surface Mount |
|
IRF8915PBFHEXFET POWER MOSFET |
3,967 | 1.00 |
RFQ |
Datasheet |
Tube | HEXFET® | Obsolete | 2 N-Channel (Dual) | Logic Level Gate | 20V | 8.9A | 18.3mOhm @ 8.9A, 10V | 2.5V @ 250µA | 7.4nC @ 4.5V | 540pF @ 10V | 2W | -55°C ~ 150°C (TJ) | Surface Mount |
|
IRF120CECCPFET, 9.2A I(D), 100V, 0.27OHM |
3,736 | 0.00 |
RFQ |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | |
|
IRF7307PBFAUTOMOTIVE HEXFET P-CHANNEL |
3,472 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N and P-Channel | Logic Level Gate | 20V | 5.2A, 4.3A | 50mOhm @ 2.6A, 4.5V | 700mV @ 250µA | 20nC @ 4.5V | 660pF @ 15V | 2W | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
IRF7101PBFHEXFET POWER MOSFET |
3,201 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | 2 N-Channel (Dual) | Logic Level Gate | 20V | 3.5A | 100mOhm @ 1.8A, 10V | 3V @ 250µA | 15nC @ 10V | 320pF @ 15V | 2W | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
IRF7306PBFAUTOMOTIVE HEXFET P-CHANNEL |
3,586 | 1.00 |
RFQ |
Bulk | HEXFET® | Active | 2 P-Channel (Dual) | Logic Level Gate | 30V | 3.6A (Ta) | 100mOhm @ 1.8A, 10V | 1V @ 250µA | 25nC @ 10V | 440pF @ 25V | 2W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
|
IRF1404PBF-ELHEXFET POWER MOSFET |
2,092 | 1.00 |
RFQ |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | |
|
IRFIRL60B216HEXFET POWER MOSFET |
3,011 | 1.00 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - |
|
IRF7313PBFHEXFET POWER MOSFET |
2,746 | 1.00 |
RFQ |
Bulk | HEXFET® | Active | 2 N-Channel (Dual) | Standard | 30V | 6.5A | 29mOhm @ 5.8A, 10V | 1V @ 250µA | 33nC @ 10V | 650pF @ 25V | 2W | -55°C ~ 150°C (TJ) | Surface Mount | |
|
IRF7304PBFAUTOMOTIVE HEXFET P-CHANNEL |
2,994 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | 2 P-Channel (Dual) | Logic Level Gate | 20V | 4.3A (Ta) | 90mOhm @ 2.2A, 4.5V | 700mV @ 250µA | 22nC @ 4.5V | 610pF @ 15V | 2W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
IRF7807ZPBFPROHEXFET N-CHANNEL POWER MOSFET |
3,103 | 1.00 |
RFQ |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | |
|
IRF7389PBFMOSFET |
3,249 | 1.00 |
RFQ |
Bulk | HEXFET® | Active | N and P-Channel | Logic Level Gate | 30V | - | 29mOhm @ 5.8A, 10V | 1V @ 250µA | 33nC @ 10V | 650pF @ 25V | 2.5W | -55°C ~ 150°C (TJ) | Surface Mount | |
|
IRFF311TRANS MOSFET N-CH 350V 5.5A |
2,735 | 0.00 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - |
|
|
IRFF9211AUTOMOTIVE HEXFET P-CHANNEL |
3,781 | 0.00 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - |
|
|
IRF7905TRPBFIRF7905 - 12V-300V N-CHANNEL POW |
2,459 | 0.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | 2 N-Channel (Dual) | Logic Level Gate | 30V | 7.8A, 8.9A | 21.8mOhm @ 7.8A, 10V | 2.25V @ 25µA | 6.9nC @ 4.5V | 600pF @ 15V | 2W | -55°C ~ 150°C (TJ) | Surface Mount |
|
IRF7307QTRPBFIRF7307 - 20V-60V COMPLEMENTARY |
2,548 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Obsolete | N and P-Channel | Logic Level Gate | 20V | 5.2A, 4.3A | 50mOhm @ 2.6A, 4.5V | 700mV @ 250µA | 20nC @ 4.5V | 660pF @ 15V | 2W | - | Surface Mount |
|
|
AUIRF7379QTRAUIRF7379Q - 30V-55V DUAL N AND |
2,185 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N and P-Channel | Logic Level Gate | 30V | 5.8A, 4.3A | 45mOhm @ 5.8A, 10V | 3V @ 250µA | 25nC @ 10V | 520pF @ 25V | 2.5W | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
IRFI4212H-117PIRFI4212 - 12V-300V N-CHANNEL PO |
3,704 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | 2 N-Channel (Dual) | Standard | 100V | 11A | 72.5mOhm @ 6.6A, 10V | 5V @ 250µA | 18nC @ 10V | 490pF @ 50V | 18W | -55°C ~ 150°C (TJ) | Through Hole |
|
|
IRF8313TRPBFIRF8313 - HEXFET POWER MOSFET |
3,137 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | 2 N-Channel (Dual) | Logic Level Gate | 30V | 9.7A | 15.5mOhm @ 9.7A, 10V | 2.35V @ 25µA | 9nC @ 4.5V | 760pF @ 15V | 2W | -55°C ~ 175°C (TJ) | Surface Mount |
