Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	FETType	Technology	DraintoSourceVoltage(Vdss)	Current-ContinuousDrain(Id)@25°C	DriveVoltage(MaxRdsOnMinRdsOn)	RdsOn(Max)@IdVgs	Vgs(th)(Max)@Id	GateCharge(Qg)(Max)@Vgs	Vgs(Max)	InputCapacitance(Ciss)(Max)@Vds	FETFeature	PowerDissipation(Max)	OperatingTemperature	MountingType
CSD18510KTT MOSFET N-CH 40V 274A DDPAK Texas Instruments	3,339	2.62	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	NexFET™	Active	N-Channel	MOSFET (Metal Oxide)	40 V	274A (Tc)	4.5V, 10V	1.7mOhm @ 100A, 10V	2.3V @ 250µA	153 nC @ 10 V	±20V	11400 pF @ 20 V	-	250W (Ta)	-55°C ~ 175°C (TJ)	Surface Mount
CSD17308Q3 MOSFET N-CH 30V 14A/44A 8VSON Texas Instruments	2,391	1.00	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT),Bulk	NexFET™	Active	N-Channel	MOSFET (Metal Oxide)	30 V	14A (Ta), 44A (Tc)	3V, 8V	10.3mOhm @ 10A, 8V	1.8V @ 250µA	5.1 nC @ 4.5 V	+10V, -8V	700 pF @ 15 V	-	2.7W (Ta)	-55°C ~ 150°C (TJ)	Surface Mount
CSD18563Q5A MOSFET N-CH 60V 100A 8VSON Texas Instruments	3,111	1.65	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	NexFET™	Active	N-Channel	MOSFET (Metal Oxide)	60 V	100A (Ta)	4.5V, 10V	6.8mOhm @ 18A, 10V	2.4V @ 250µA	20 nC @ 10 V	±20V	1500 pF @ 30 V	-	3.2W (Ta), 116W (Tc)	-55°C ~ 150°C (TJ)	Surface Mount
CSD16321Q5 MOSFET N-CH 25V 31A/100A 8VSON Texas Instruments	3,892	1.83	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT),Bulk	NexFET™	Active	N-Channel	MOSFET (Metal Oxide)	25 V	31A (Ta), 100A (Tc)	3V, 8V	2.4mOhm @ 25A, 8V	1.4V @ 250µA	19 nC @ 4.5 V	+10V, -8V	3100 pF @ 12.5 V	-	3.1W (Ta)	-55°C ~ 150°C (TJ)	Surface Mount
TPIC5322LD N-CHANNEL POWER MOSFET Texas Instruments	3,020	1.00	RFQ		Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-
FDP032N08 120A, 75V, 0.0032OHM, N CHANNEL Texas Instruments	3,198	1.00	RFQ	Datasheet	Bulk	-	Active	N-Channel	MOSFET (Metal Oxide)	75 V	120A (Tc)	10V	3.2mOhm @ 75A, 10V	4.5V @ 250µA	220 nC @ 10 V	±20V	15160 pF @ 25 V	-	375W (Tc)	-55°C ~ 175°C (TJ)	Through Hole
CSD18542KTT MOSFET N-CH 60V 200A DDPAK Texas Instruments	3,066	2.79	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	NexFET™	Active	N-Channel	MOSFET (Metal Oxide)	60 V	200A (Ta)	4.5V, 10V	4mOhm @ 100A, 10V	2.2V @ 250µA	57 nC @ 10 V	±20V	5070 pF @ 30 V	-	250W (Tc)	-55°C ~ 175°C (TJ)	Surface Mount
CSD18540Q5BT MOSFET N-CH 60V 100A 8VSON Texas Instruments	3,484	3.16	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	NexFET™	Active	N-Channel	MOSFET (Metal Oxide)	60 V	100A (Ta)	4.5V, 10V	2.2mOhm @ 28A, 10V	2.3V @ 250µA	53 nC @ 10 V	±20V	4230 pF @ 30 V	-	3.1W (Ta), 195W (Tc)	-55°C ~ 150°C (TJ)	Surface Mount
TPIC5421LDW N-CHANNEL POWER MOSFET Texas Instruments	3,467	0.00	RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-
TPIC1301DW N-CHANNEL POWER MOSFET Texas Instruments	2,884	0.00	RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-
CSD25501F3 MOSFET P-CH 20V 3.6A 3LGA Texas Instruments	3,150	0.10	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	FemtoFET™	Active	P-Channel	MOSFET (Metal Oxide)	20 V	3.6A (Ta)	1.8V, 4.5V	76mOhm @ 400mA, 4.5V	1.05V @ 250µA	1.33 nC @ 4.5 V	-20V	385 pF @ 10 V	-	500mW (Ta)	-55°C ~ 150°C (TJ)	Surface Mount
CSD23203W MOSFET P-CH 8V 3A 6DSBGA Texas Instruments	3,803	0.20	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	NexFET™	Active	P-Channel	MOSFET (Metal Oxide)	8 V	3A (Ta)	1.8V, 4.5V	19.4mOhm @ 1.5A, 4.5V	1.1V @ 250µA	6.3 nC @ 4.5 V	-6V	914 pF @ 4 V	-	750mW (Ta)	-55°C ~ 150°C (TJ)	Surface Mount
CSD13303W1015 MOSFET N-CH 12V 31A 6DSBGA Texas Instruments	2,893	0.53	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	NexFET™	Active	N-Channel	MOSFET (Metal Oxide)	12 V	31A (Ta)	2.5V, 4.5V	20mOhm @ 1.5A, 4.5V	1.2V @ 250µA	4.7 nC @ 4.5 V	±8V	715 pF @ 6 V	-	1.65W (Ta)	-55°C ~ 150°C (TJ)	Surface Mount
CSD25304W1015 MOSFET P-CH 20V 3A 6DSBGA Texas Instruments	3,640	0.21	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	NexFET™	Active	P-Channel	MOSFET (Metal Oxide)	20 V	3A (Ta)	1.8V, 4.5V	32.5mOhm @ 1.5A, 4.5V	1.15V @ 250µA	4.4 nC @ 4.5 V	±8V	595 pF @ 10 V	-	750mW (Ta)	-55°C ~ 150°C (TJ)	Surface Mount
CSD22204W MOSFET P-CH 8V 5A 9DSBGA Texas Instruments	2,940	0.25	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	NexFET™	Active	P-Channel	MOSFET (Metal Oxide)	8 V	5A (Ta)	2.5V, 4.5V	9.9mOhm @ 2A, 4.5V	950mV @ 250µA	24.6 nC @ 4.5 V	-6V	1130 pF @ 4 V	-	1.7W (Ta)	-55°C ~ 150°C (TJ)	Surface Mount
CSD25202W15 MOSFET P-CH 20V 4A 9DSBGA Texas Instruments	3,184	0.27	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	NexFET™	Active	P-Channel	MOSFET (Metal Oxide)	20 V	4A (Ta)	1.8V, 4.5V	26mOhm @ 2A, 4.5V	1.05V @ 250µA	7.5 nC @ 4.5 V	-6V	1010 pF @ 10 V	-	500mW (Ta)	-55°C ~ 150°C (TJ)	Surface Mount
CSD17381F4T MOSFET N-CH 30V 3.1A 3PICOSTAR Texas Instruments	3,250	0.41	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	FemtoFET™	Active	N-Channel	MOSFET (Metal Oxide)	30 V	3.1A (Ta)	1.8V, 4.5V	109mOhm @ 500mA, 8V	1.1V @ 250µA	1.35 nC @ 4.5 V	12V	195 pF @ 15 V	-	500mW (Ta)	-55°C ~ 150°C (TJ)	Surface Mount
CSD17327Q5A MOSFET N-CH 30V 65A 8VSON Texas Instruments	3,045	1.00	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT),Bulk	NexFET™	Active	N-Channel	MOSFET (Metal Oxide)	30 V	65A (Tc)	4.5V, 8V	12.2mOhm @ 11A, 8V	2V @ 250µA	3.4 nC @ 4.5 V	±10V	506 pF @ 15 V	-	3W (Ta)	-55°C ~ 150°C (TJ)	Surface Mount
CSD17322Q5A MOSFET N-CH 30V 87A 8VSON Texas Instruments	3,666	0.50	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	NexFET™	Active	N-Channel	MOSFET (Metal Oxide)	30 V	87A (Tc)	4.5V, 8V	8.8mOhm @ 14A, 8V	2V @ 250µA	4.3 nC @ 4.5 V	±10V	695 pF @ 15 V	-	3W (Ta)	-55°C ~ 150°C (TJ)	Surface Mount
CSD16408Q5 MOSFET N-CH 25V 22A/113A 8VSON Texas Instruments	27,665	0.68	RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT),Bulk	NexFET™	Active	N-Channel	MOSFET (Metal Oxide)	25 V	22A (Ta), 113A (Tc)	4.5V, 10V	4.5mOhm @ 25A, 10V	2.1V @ 250µA	8.9 nC @ 4.5 V	+16V, -12V	1300 pF @ 12.5 V	-	3.1W (Ta)	-55°C ~ 150°C (TJ)	Surface Mount
