| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
IRFS5615TRLPBFMOSFET N-CH 150V 33A D2PAK |
2,287 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 150 V | 33A (Tc) | 10V | 42mOhm @ 21A, 10V | 5V @ 100µA | 40 nC @ 10 V | ±20V | 1750 pF @ 50 V | - | 144W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
IRF1404ZGPBFMOSFET N-CH 40V 180A TO220AB |
2,487 | 0.00 |
RFQ |
Datasheet |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 40 V | 180A (Tc) | 10V | 3.7mOhm @ 75A, 10V | 4V @ 250µA | 150 nC @ 10 V | ±20V | 4340 pF @ 25 V | - | 220W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
|
IRFB3004GPBFMOSFET N-CH 40V 195A TO220AB |
2,815 | 0.00 |
RFQ |
Datasheet |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 40 V | 195A (Tc) | 10V | 1.75mOhm @ 195A, 10V | 4V @ 250µA | 240 nC @ 10 V | ±20V | 9200 pF @ 25 V | - | 380W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
IRF7665S2TR1PBFMOSFET N-CH 100V 4.1A DIRECTFET |
2,614 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 100 V | 4.1A (Ta), 14.4A (Tc) | 10V | 62mOhm @ 8.9A, 10V | 5V @ 25µA | 13 nC @ 10 V | ±20V | 515 pF @ 25 V | - | 2.4W (Ta), 30W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
IRF8707GTRPBFMOSFET N-CH 30V 11A 8SO |
2,625 | 1.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Bulk | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 11A (Ta) | 4.5V, 10V | 11.9mOhm @ 11A, 10V | 2.35V @ 25µA | 9.3 nC @ 4.5 V | ±20V | 760 pF @ 15 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
IRF8714GTRPBFMOSFET N-CH 30V 14A 8SO |
3,283 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 14A (Ta) | 4.5V, 10V | 8.7mOhm @ 14A, 10V | 2.35V @ 25µA | 12 nC @ 4.5 V | ±20V | 1020 pF @ 15 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
IRF8721GTRPBFMOSFET N-CH 30V 14A 8SO |
2,538 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 14A (Ta) | 4.5V, 10V | 8.5mOhm @ 14A, 10V | 2.35V @ 25µA | 12 nC @ 4.5 V | ±20V | 1040 pF @ 15 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
IRF8707GPBFMOSFET N-CH 30V 11A 8SO |
3,244 | 0.00 |
RFQ |
Datasheet |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 11A (Ta) | 4.5V, 10V | 11.9mOhm @ 11A, 10V | 2.35V @ 25µA | 9.3 nC @ 4.5 V | ±20V | 760 pF @ 15 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
IRF8714GPBFMOSFET N-CH 30V 14A 8SO |
2,740 | 0.00 |
RFQ |
Datasheet |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 14A (Ta) | 4.5V, 10V | 8.7mOhm @ 14A, 10V | 2.35V @ 25µA | 12 nC @ 4.5 V | ±20V | 1020 pF @ 15 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
IRF8721GPBFMOSFET N-CH 30V 14A 8SO |
3,970 | 0.00 |
RFQ |
Datasheet |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 14A (Ta) | 4.5V, 10V | 8.5mOhm @ 14A, 10V | 2.35V @ 25µA | 12 nC @ 4.5 V | ±20V | 1040 pF @ 15 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
IRF6718L2TR1PBFMOSFET N-CH 25V 61A DIRECTFET |
3,627 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 25 V | 61A (Ta), 270A (Tc) | 4.5V, 10V | 0.7mOhm @ 61A, 10V | 2.35V @ 150µA | 96 nC @ 4.5 V | ±20V | 6500 pF @ 13 V | - | 4.3W (Ta), 83W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
IRFH5306TRPBFMOSFET N-CH 30V 15A/44A PQFN |
2,642 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 15A (Ta), 44A (Tc) | 4.5V, 10V | 8.1mOhm @ 15A, 10V | 2.35V @ 25µA | 12 nC @ 4.5 V | ±20V | 1125 pF @ 15 V | - | 3.6W (Ta), 26W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
IRFH5301TR2PBFMOSFET N-CH 30V 35A 5X6 PQFN |
2,165 | 0.00 |
RFQ |
Datasheet |
Cut Tape (CT) | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 35A (Ta), 100A (Tc) | - | 1.85mOhm @ 50A, 10V | 2.35V @ 100µA | 77 nC @ 10 V | - | 5114 pF @ 15 V | - | - | - | Surface Mount |
|
|
IRFH5302TR2PBFMOSFET N-CH 30V 32A 5X6 PQFN |
3,512 | 0.00 |
RFQ |
Datasheet |
Cut Tape (CT) | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 32A (Ta), 100A (Tc) | - | 2.1mOhm @ 50A, 10V | 2.35V @ 100µA | 76 nC @ 10 V | - | 4400 pF @ 15 V | - | - | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
IRFH5306TR2PBFMOSFET N-CH 30V 15A 5X6 PQFN |
3,064 | 0.00 |
RFQ |
Datasheet |
Cut Tape (CT) | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 15A (Ta), 44A (Tc) | - | 8.1mOhm @ 15A, 10V | 2.35V @ 25µA | 12 nC @ 4.5 V | - | 1125 pF @ 15 V | - | - | - | Surface Mount |
|
IRF7739L2TR1PBFMOSFET N-CH 40V 46A DIRECTFET |
2,785 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 40 V | 46A (Ta), 375A (Tc) | 10V | 1mOhm @ 160A, 10V | 4V @ 250µA | 330 nC @ 10 V | ±20V | 11880 pF @ 25 V | - | 3.8W (Ta), 125W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
IRF7749L2TR1PBFMOSFET N-CH 60V 33A DIRECTFET |
2,734 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 60 V | 33A (Ta), 375A (Tc) | 10V | 1.5mOhm @ 120A, 10V | 4V @ 250µA | 300 nC @ 10 V | ±20V | 12320 pF @ 25 V | - | 3.3W (Ta), 125W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
IRF7759L2TR1PBFMOSFET N-CH 75V 26A DIRECTFET |
3,313 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 75 V | 26A (Ta), 375A (Tc) | 10V | 2.3mOhm @ 96A, 10V | 4V @ 250µA | 300 nC @ 10 V | ±20V | 12222 pF @ 25 V | - | 3.3W (Ta), 125W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
IRF7769L2TR1PBFMOSFET N-CH 100V 375A DIRECTFET |
2,364 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 100 V | 375A (Tc) | 10V | 3.5mOhm @ 74A, 10V | 4V @ 250µA | 300 nC @ 10 V | ±20V | 11560 pF @ 25 V | - | 3.3W (Ta), 125W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
IRF7779L2TR1PBFMOSFET N-CH 150V 375A DIRECTFET |
3,879 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 150 V | 375A (Tc) | 10V | 11mOhm @ 40A, 10V | 5V @ 250µA | 150 nC @ 10 V | ±20V | 6660 pF @ 25 V | - | 3.3W (Ta), 125W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
