Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	FETType	Technology	DraintoSourceVoltage(Vdss)	Current-ContinuousDrain(Id)@25°C	DriveVoltage(MaxRdsOnMinRdsOn)	RdsOn(Max)@IdVgs	Vgs(th)(Max)@Id	GateCharge(Qg)(Max)@Vgs	Vgs(Max)	InputCapacitance(Ciss)(Max)@Vds	FETFeature	PowerDissipation(Max)	OperatingTemperature	MountingType
PMZ290UN315 SMALL SIGNAL FET NXP USA Inc.	19,000	0.08	RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-
PMZB380XN,315 MOSFET N-CH 30V 930MA DFN1006B-3 NXP USA Inc.	243,343	0.09	RFQ	Datasheet	Bulk	-	Obsolete	N-Channel	MOSFET (Metal Oxide)	30 V	930mA (Ta)	2.5V, 4.5V	460mOhm @ 200mA, 4.5V	1.5V @ 250µA	0.87 nC @ 4.5 V	±12V	56 pF @ 25 V	-	360mW (Ta), 2.7W (Tc)	-55°C ~ 150°C (TJ)	Surface Mount
PMCXB1000UE147 P-CHANNEL MOSFET NXP USA Inc.	235,000	0.09	RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-
PMZB300XN,315 MOSFET N-CH 20V 1A DFN1006B-3 NXP USA Inc.	230,000	0.09	RFQ	Datasheet	Bulk	-	Obsolete	N-Channel	MOSFET (Metal Oxide)	20 V	1A (Ta)	2.5V, 4.5V	380mOhm @ 200mA, 4.5V	1.5V @ 250µA	0.94 nC @ 4.5 V	±12V	51 pF @ 20 V	-	360mW (Ta), 2.7W (Tc)	-55°C ~ 150°C (TJ)	Surface Mount
PMZB790SN,315 MOSFET N-CH 60V 650MA DFN1006B-3 NXP USA Inc.	168,722	0.09	RFQ	Datasheet	Bulk	-	Obsolete	N-Channel	MOSFET (Metal Oxide)	60 V	650mA (Ta)	4.5V, 10V	940mOhm @ 300mA, 10V	3V @ 250µA	1.37 nC @ 10 V	±20V	35 pF @ 30 V	-	360mW (Ta), 2.7W (Tc)	-55°C ~ 150°C (TJ)	Surface Mount
PMZB420UN,315 MOSFET N-CH 30V 900MA DFN1006B-3 NXP USA Inc.	116,752	0.09	RFQ	Datasheet	Bulk	-	Obsolete	N-Channel	MOSFET (Metal Oxide)	30 V	900mA (Ta)	1.8V, 4.5V	490mOhm @ 200mA, 4.5V	950mV @ 250µA	0.98 nC @ 4.5 V	±8V	65 pF @ 25 V	-	360mW (Ta), 2.7W (Tc)	-55°C ~ 150°C (TJ)	Surface Mount
PMN45EN,135 MOSFET N-CH 30V 5.2A 6TSOP NXP USA Inc.	450,515	0.17	RFQ	Datasheet	Bulk	TrenchMOS™	Active	N-Channel	MOSFET (Metal Oxide)	30 V	5.2A (Tc)	-	40mOhm @ 3A, 10V	2V @ 1mA	6.1 nC @ 4.5 V	20V	495 pF @ 25 V	-	1.75W (Tc)	150°C (TJ)	Surface Mount
ON5257215 SMALL SIGNAL N-CHANNEL MOSFET NXP USA Inc.	96,000	0.17	RFQ		Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-
PMFPB8040XP,115 MOSFET P-CH 20V 2.7A HUSON6 NXP USA Inc.	161,589	0.18	RFQ	Datasheet	Bulk	-	Obsolete	P-Channel	MOSFET (Metal Oxide)	20 V	2.7A (Ta)	1.8V, 4.5V	102mOhm @ 2.7A, 4.5V	1V @ 250µA	8.6 nC @ 4.5 V	±12V	550 pF @ 10 V	Schottky Diode (Isolated)	485mW (Ta), 6.25W (Tc)	-55°C ~ 150°C (TJ)	Surface Mount
PMN27XPE115 SMALL SIGNAL FET NXP USA Inc.	34,557	0.21	RFQ	Datasheet	Bulk	-	Active	P-Channel	MOSFET (Metal Oxide)	20 V	4.4A (Ta)	2.5V, 4.5V	30mOhm @ 3A, 4.5V	1.25V @ 250µA	22.5 nC @ 4.5 V	±12V	1770 pF @ 10 V	-	530mW (Ta), 8.33W (Tc)	-55°C ~ 150°C (TJ)	Surface Mount
ON5258215 NOW NEXPERIA ON5258 - RF MOSFET NXP USA Inc.	696,000	0.22	RFQ		Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-
BSP126/S911115 N-CHANNEL POWER MOSFET NXP USA Inc.	204,767	0.22	RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-
BUK9245-55A/C1118 N-CHANNEL POWER MOSFET NXP USA Inc.	15,000	0.22	RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-
BUK6228-55C,118 PFET, 31A I(D), 55V, 0.044OHM, 1 NXP USA Inc.	2,867	0.22	RFQ	Datasheet	Bulk	Automotive, AEC-Q101, TrenchMOS™	Active	N-Channel	MOSFET (Metal Oxide)	55 V	31A (Tc)	10V	29mOhm @ 10A, 10V	2.8V @ 1mA	20.2 nC @ 10 V	±16V	1340 pF @ 25 V	-	60W (Tc)	-55°C ~ 175°C (TJ)	Surface Mount
PSMN6R0-25YLD115 N-CHANNEL POWER MOSFET NXP USA Inc.	39,000	0.24	RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-
PH9130AL115 SMALL SIGNAL N-CHANNEL MOSFET NXP USA Inc.	511,500	0.25	RFQ		Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-
PMN40UPEA115 P-CHANNEL MOSFET NXP USA Inc.	46,497	0.25	RFQ	Datasheet	Bulk	-	Active	P-Channel	MOSFET (Metal Oxide)	20 V	4.7A (Ta)	1.8V, 4.5V	43mOhm @ 3A, 4.5V	950mV @ 250µA	23 nC @ 4.5 V	±8V	1820 pF @ 10 V	-	500mW (Ta), 8.33W (Tc)	-55°C ~ 150°C (TJ)	Surface Mount
BSP225/S911115 P-CHANNEL MOSFET NXP USA Inc.	313,000	0.26	RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-
BSH207,135 MOSFET P-CH 12V 1.52A 6TSOP NXP USA Inc.	66,873	0.27	RFQ	Datasheet	Bulk	-	Obsolete	P-Channel	MOSFET (Metal Oxide)	12 V	1.52A (Ta)	1.8V, 4.5V	120mOhm @ 1A, 4.5V	600mV @ 1mA (Typ)	8.8 nC @ 4.5 V	±8V	500 pF @ 9.6 V	-	417mW (Ta)	-55°C ~ 150°C (TJ)	Surface Mount
BUK9230-55A/C1118 N-CHANNEL POWER MOSFET NXP USA Inc.	31,793	0.27	RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-
