Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	IGBTType	Voltage-CollectorEmitterBreakdown(Max)	Current-Collector(Ic)(Max)	Current-CollectorPulsed(Icm)	Vce(on)(Max)@VgeIc	Power-Max	SwitchingEnergy	InputType	GateCharge	Td(on/off)@25°C	TestCondition	ReverseRecoveryTime(trr)	OperatingTemperature	MountingType
GN2470K4-G IC IGBT 700V 3.5A 3DPAK Microchip Technology	2,752	1.34	RFQ	Datasheet	Tape & Reel (TR)	-	Active	-	700 V	1 A	3.5 A	5V @ 13V, 3A	2.5 W	-	Standard	-	8ns/20ns	-	-	-55°C ~ 150°C (TJ)	Surface Mount
APT30GN60BDQ2G IGBT 600V 63A 203W TO247 Microchip Technology	2,938	4.58	RFQ	Datasheet	Tube	-	Active	Trench Field Stop	600 V	63 A	90 A	1.9V @ 15V, 30A	203 W	525µJ (on), 700µJ (off)	Standard	165 nC	12ns/155ns	400V, 30A, 4.3Ohm, 15V	-	-55°C ~ 175°C (TJ)	Through Hole
APT20GN60BDQ1G IGBT 600V 40A 136W TO247 Microchip Technology	2,105	3.42	RFQ	Datasheet	Tube	-	Active	Trench Field Stop	600 V	40 A	60 A	1.9V @ 15V, 20A	136 W	230µJ (on), 580µJ (off)	Standard	120 nC	9ns/140ns	400V, 20A, 4.3Ohm, 15V	-	-55°C ~ 175°C (TJ)	Through Hole
APT30GN60BG IGBT 600V 63A 203W TO247 Microchip Technology	2,540	3.47	RFQ	Datasheet	Tube	-	Active	Trench Field Stop	600 V	63 A	90 A	1.9V @ 15V, 30A	203 W	525µJ (on), 700µJ (off)	Standard	165 nC	12ns/155ns	400V, 30A, 4.3Ohm, 15V	-	-55°C ~ 175°C (TJ)	Through Hole
APT20GN60BG IGBT 600V 40A 136W TO247 Microchip Technology	3,254	4.04	RFQ	Datasheet	Tube	-	Active	Trench Field Stop	600 V	40 A	60 A	1.9V @ 15V, 20A	136 W	230µJ (on), 580µJ (off)	Standard	120 nC	9ns/140ns	400V, 20A, 4.3Ohm, 15V	-	-55°C ~ 175°C (TJ)	Through Hole
APT15GP60BG IGBT 600V 56A 250W TO247 Microchip Technology	3,645	4.61	RFQ	Datasheet	Tube	POWER MOS 7®	Active	PT	600 V	56 A	65 A	2.7V @ 15V, 15A	250 W	130µJ (on), 121µJ (off)	Standard	55 nC	8ns/29ns	400V, 15A, 5Ohm, 15V	-	-55°C ~ 150°C (TJ)	Through Hole
APT35GA90B IGBT 900V 63A 290W TO-247 Microchip Technology	2,414	4.88	RFQ	Datasheet	Tube	POWER MOS 8™	Active	PT	900 V	63 A	105 A	3.1V @ 15V, 18A	290 W	642µJ (on), 382µJ (off)	Standard	84 nC	12ns/104ns	600V, 18A, 10Ohm, 15V	-	-55°C ~ 150°C (TJ)	Through Hole
APT15GT120BRDQ1G IGBT 1200V 36A 250W TO247 Microchip Technology	3,205	5.01	RFQ	Datasheet	Tube	Thunderbolt IGBT®	Active	NPT	1200 V	36 A	45 A	3.6V @ 15V, 15A	250 W	585µJ (on), 260µJ (off)	Standard	105 nC	10ns/85ns	800V, 15A, 5Ohm, 15V	-	-55°C ~ 150°C (TJ)	Through Hole
APT15GP60BDQ1G IGBT 600V 56A 250W TO247 Microchip Technology	3,661	5.27	RFQ	Datasheet	Tube	POWER MOS 7®	Active	PT	600 V	56 A	65 A	2.7V @ 15V, 15A	250 W	130µJ (on), 120µJ (off)	Standard	55 nC	8ns/29ns	400V, 15A, 5Ohm, 15V	-	-55°C ~ 150°C (TJ)	Through Hole
APT54GA60B IGBT 600V 96A 416W TO-247 Microchip Technology	3,267	6.39	RFQ	Datasheet	Tube	POWER MOS 8™	Active	PT	600 V	96 A	161 A	2.5V @ 15V, 32A	416 W	534µJ (on), 466µJ (off)	Standard	158 nC	17ns/112ns	400V, 32A, 4.7Ohm, 15V	-	-55°C ~ 150°C (TJ)	Through Hole
APT15GP90BDQ1G IGBT 900V 43A 250W TO247 Microchip Technology	2,545	6.42	RFQ	Datasheet	Tube	POWER MOS 7®	Active	PT	900 V	43 A	60 A	3.9V @ 15V, 15A	250 W	200µJ (off)	Standard	60 nC	9ns/33ns	600V, 15A, 4.3Ohm, 15V	-	-55°C ~ 150°C (TJ)	Through Hole
APT20GN60SDQ2G IGBT FIELDSTOP COMBI 600V 20A TO Microchip Technology	3,755	6.46	RFQ	Datasheet	Tube	-	Active	Trench Field Stop	600 V	40 A	60 A	1.9V @ 15V, 20A	136 W	230µJ (on), 580µJ (off)	Standard	120 nC	9ns/140ns	400V, 20A, 4.3Ohm, 15V	30 ns	-55°C ~ 175°C (TJ)	Surface Mount
APT13GP120BG IGBT 1200V 41A 250W TO247 Microchip Technology	2,827	6.53	RFQ	Datasheet	Tube	POWER MOS 7®	Active	PT	1200 V	41 A	50 A	3.9V @ 15V, 13A	250 W	115µJ (on), 165µJ (off)	Standard	55 nC	9ns/28ns	600V, 13A, 5Ohm, 15V	-	-55°C ~ 150°C (TJ)	Through Hole
APT15GN120BDQ1G IGBT 1200V 45A 195W TO247 Microchip Technology	3,921	6.88	RFQ	Datasheet	Tube	-	Active	Trench Field Stop	1200 V	45 A	45 A	2.1V @ 15V, 15A	195 W	410µJ (on), 950µJ (off)	Standard	90 nC	10ns/150ns	800V, 15A, 4.3Ohm, 15V	-	-55°C ~ 150°C (TJ)	Through Hole
APT50GT60BRG IGBT 600V 110A 446W TO247 Microchip Technology	3,812	6.96	RFQ	Datasheet	Tube	Thunderbolt IGBT®	Active	NPT	600 V	110 A	150 A	2.5V @ 15V, 50A	446 W	995µJ (on), 1070µJ (off)	Standard	240 nC	14ns/240ns	400V, 50A, 4.3Ohm, 15V	-	-55°C ~ 150°C (TJ)	Through Hole
APT44GA60BD30 IGBT 600V 78A 337W TO-247 Microchip Technology	3,555	7.02	RFQ	Datasheet	Tube	POWER MOS 8™	Active	PT	600 V	78 A	130 A	2.5V @ 15V, 26A	337 W	409µJ (on), 258µJ (off)	Standard	128 nC	16ns/84ns	400V, 26A, 4.7Ohm, 15V	-	-55°C ~ 150°C (TJ)	Through Hole
APT75GN60BG IGBT 600V 155A 536W TO247 Microchip Technology	2,265	7.04	RFQ	Datasheet	Tube	-	Active	Trench Field Stop	600 V	155 A	225 A	1.85V @ 15V, 75A	536 W	2500µJ (on), 2140µJ (off)	Standard	485 nC	47ns/385ns	400V, 75A, 1Ohm, 15V	-	-55°C ~ 175°C (TJ)	Through Hole
APT13GP120BDQ1G IGBT 1200V 41A 250W TO247 Microchip Technology	2,077	7.38	RFQ	Datasheet	Tube	POWER MOS 7®	Active	PT	1200 V	41 A	50 A	3.9V @ 15V, 13A	250 W	115µJ (on), 165µJ (off)	Standard	55 nC	9ns/28ns	600V, 13A, 5Ohm, 15V	-	-55°C ~ 150°C (TJ)	Through Hole
APT44GA60B IGBT 600V 78A 337W TO-247 Microchip Technology	2,934	7.57	RFQ	Datasheet	Tube	POWER MOS 8™	Active	PT	600 V	78 A	130 A	2.5V @ 15V, 26A	337 W	409µJ (on), 258µJ (off)	Standard	128 nC	16ns/84ns	400V, 26A, 4.7Ohm, 15V	-	-55°C ~ 150°C (TJ)	Through Hole
APT54GA60BD30 IGBT 600V 96A 416W TO247 Microchip Technology	3,073	7.70	RFQ	Datasheet	Tube	-	Active	PT	600 V	96 A	161 A	2.5V @ 15V, 32A	416 W	534µJ (on), 466µJ (off)	Standard	28 nC	17ns/112ns	400V, 32A, 4.7Ohm, 15V	-	-55°C ~ 150°C (TJ)	Through Hole
