Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	IGBTType	Voltage-CollectorEmitterBreakdown(Max)	Current-Collector(Ic)(Max)	Current-CollectorPulsed(Icm)	Vce(on)(Max)@VgeIc	Power-Max	SwitchingEnergy	InputType	GateCharge	Td(on/off)@25°C	TestCondition	ReverseRecoveryTime(trr)	OperatingTemperature	MountingType
RGCL80TK60DGC11 IGBT Rohm Semiconductor	448	6.01	RFQ	Datasheet	Tube	-	Active	Trench Field Stop	600 V	35 A	160 A	1.8V @ 15V, 40A	57 W	1.11mJ (on), 1.68mJ (off)	Standard	98 nC	53ns/227ns	400V, 40A, 10Ohm, 15V	58 ns	-40°C ~ 175°C (TJ)	Through Hole
RGW00TS65GC11 650V 50A FIELD STOP TRENCH IGBT Rohm Semiconductor	439	6.07	RFQ	Datasheet	Tube	-	Active	Trench Field Stop	650 V	96 A	200 A	1.9V @ 15V, 50A	254 W	1.18mJ (on), 960µJ (off)	Standard	141 nC	52ns/180ns	400V, 50A, 10Ohm, 15V	-	-40°C ~ 175°C (TJ)	Through Hole
RGTV00TS65GC11 650V 50A FIELD STOP TRENCH IGBT Rohm Semiconductor	324	6.24	RFQ	Datasheet	Tube	-	Active	Trench Field Stop	650 V	95 A	200 A	1.9V @ 15V, 50A	276 W	1.17mJ (on), 940µJ (off)	Standard	104 nC	41ns/142ns	400V, 50A, 10Ohm, 15V	-	-40°C ~ 175°C (TJ)	Through Hole
RGTH50TK65DGC11 IGBT Rohm Semiconductor	450	6.28	RFQ	Datasheet	Tube	-	Active	Trench Field Stop	650 V	26 A	100 A	2.1V @ 15V, 25A	59 W	-	Standard	49 nC	27ns/94ns	400V, 25A, 10Ohm, 15V	58 ns	-40°C ~ 175°C (TJ)	Through Hole
RGTH80TK65GC11 IGBT Rohm Semiconductor	450	6.34	RFQ	Datasheet	Tube	-	Active	Trench Field Stop	650 V	31 A	160 A	2.1V @ 15V, 40A	66 W	-	Standard	79 nC	34ns/120ns	400V, 40A, 10Ohm, 15V	-	-40°C ~ 175°C (TJ)	Through Hole
RGW80TK65GVC11 650V 40A FIELD STOP TRENCH IGBT Rohm Semiconductor	450	6.40	RFQ	Datasheet	Tube	-	Active	Trench Field Stop	650 V	39 A	160 A	1.9V @ 15V, 40A	81 W	760µJ (on), 720µJ (off)	Standard	110 nC	44ns/143ns	400V, 40A, 10Ohm, 15V	-	-40°C ~ 175°C (TJ)	Through Hole
RGTH60TK65DGC11 IGBT Rohm Semiconductor	403	6.62	RFQ	Datasheet	Tube	-	Active	Trench Field Stop	650 V	28 A	120 A	2.1V @ 15V, 30A	61 W	-	Standard	58 nC	27ns/105ns	400V, 30A, 10Ohm, 15V	58 ns	-40°C ~ 175°C (TJ)	Through Hole
RGW40TS65DGC11 650V 20A FIELD STOP TRENCH IGBT Rohm Semiconductor	450	5.45	RFQ		Tube	-	Active	Trench Field Stop	650 V	40 A	80 A	1.9V @ 15V, 20A	136 W	330µJ (on), 300µJ (off)	Standard	59 nC	33ns/76ns	400V, 20A, 10Ohm, 15V	-	-40°C ~ 175°C (TJ)	Through Hole
RGW50TK65GVC11 HIGH-SPEED FAST SWITCHING TYPE Rohm Semiconductor	450	450.00	RFQ		Tube	-	Active	Trench Field Stop	650 V	30 A	100 A	1.9V @ 15V, 25A	67 W	390µJ (on), 430µJ (off)	Standard	73 nC	35ns/102ns	400V, 25A, 10Ohm, 15V	-	-40°C ~ 175°C (TJ)	Through Hole
RGTV80TS65GC11 650V 40A FIELD STOP TRENCH IGBT Rohm Semiconductor	450	5.60	RFQ		Tube	-	Active	Trench Field Stop	650 V	78 A	160 A	1.9V @ 15V, 40A	234 W	1.02mJ (on), 710µJ (off)	Standard	81 nC	39ns/113ns	400V, 40A, 10Ohm, 15V	-	-40°C ~ 175°C (TJ)	Through Hole
RGW50TS65DGC11 650V 25A FIELD STOP TRENCH IGBT Rohm Semiconductor	446	5.66	RFQ		Tube	-	Active	Trench Field Stop	650 V	50 A	100 A	1.9V @ 15V, 25A	156 W	390µJ (on), 430µJ (off)	Standard	73 nC	35ns/102ns	400V, 25A, 10Ohm, 15V	-	-40°C ~ 175°C (TJ)	Through Hole
RGTV80TK65GVC11 2US SHORT-CIRCUIT TOLERANCE, 650 Rohm Semiconductor	450	6.37	RFQ		Tube	-	Active	Trench Field Stop	650 V	39 A	160 A	1.9V @ 15V, 40A	85 W	1.02mJ (on), 710µJ (off)	Standard	81 nC	39ns/113ns	400V, 40A, 10Ohm, 15V	-	-40°C ~ 175°C (TJ)	Through Hole
RGW50TK65DGVC11 HIGH-SPEED FAST SWITCHING TYPE Rohm Semiconductor	450	450.00	RFQ		Tube	-	Active	Trench Field Stop	650 V	30 A	100 A	1.9V @ 15V, 25A	67 W	390µJ (on), 430µJ (off)	Standard	73 nC	35ns/102ns	400V, 25A, 10Ohm, 15V	92 ns	-40°C ~ 175°C (TJ)	Through Hole
RGTH40TS65GC11 IGBT 650V 40A 144W TO-247N Rohm Semiconductor	2,981	2.81	RFQ	Datasheet	Tube	-	Active	Trench Field Stop	650 V	40 A	80 A	2.1V @ 15V, 20A	144 W	-	Standard	40 nC	22ns/73ns	400V, 20A, 10Ohm, 15V	-	-40°C ~ 175°C (TJ)	Through Hole
RGTH50TS65GC11 IGBT 650V 50A 174W TO-247N Rohm Semiconductor	220	3.64	RFQ	Datasheet	Tube	-	Active	Trench Field Stop	650 V	50 A	100 A	2.1V @ 15V, 25A	174 W	-	Standard	49 nC	27ns/94ns	400V, 25A, 10Ohm, 15V	-	-40°C ~ 175°C (TJ)	Through Hole
RGTH50TS65DGC11 IGBT 650V 50A 174W TO-247N Rohm Semiconductor	188	4.01	RFQ	Datasheet	Tube	-	Active	Trench Field Stop	650 V	50 A	100 A	2.1V @ 15V, 25A	174 W	-	Standard	49 nC	27ns/94ns	400V, 25A, 10Ohm, 15V	58 ns	-40°C ~ 175°C (TJ)	Through Hole
RGTH80TS65GC11 650V 40A FIELD STOP TRENCH IGBT Rohm Semiconductor	155	4.35	RFQ	Datasheet	Tube	-	Active	Trench Field Stop	650 V	70 A	160 A	2.1V @ 15V, 40A	234 W	-	Standard	79 nC	34ns/120ns	400V, 40A, 10Ohm, 15V	-	-40°C ~ 175°C (TJ)	Through Hole
RGTH00TS65GC11 IGBT 650V 85A 277W TO-247N Rohm Semiconductor	2,792	4.75	RFQ	Datasheet	Tube	-	Active	Trench Field Stop	650 V	85 A	200 A	2.1V @ 15V, 50A	277 W	-	Standard	94 nC	39ns/143ns	400V, 50A, 10Ohm, 15V	-	-40°C ~ 175°C (TJ)	Through Hole
RGS30TSX2DGC11 10US SHORT-CIRCUIT TOLERANCE, 12 Rohm Semiconductor	2,091	7.71	RFQ	Datasheet	Tube	-	Active	Trench Field Stop	1200 V	30 A	45 A	2.1V @ 15V, 15A	267 W	740µJ (on), 600µJ (off)	Standard	41 nC	30ns/70ns	600V, 15A, 10Ohm, 15V	157 ns	-40°C ~ 175°C (TJ)	Through Hole
RGT16NS65DGTL IGBT 650V 16A 94W TO-263S Rohm Semiconductor	424	1.83	RFQ	Datasheet	Cut Tape (CT)	-	Not For New Designs	Trench Field Stop	650 V	16 A	24 A	2.1V @ 15V, 8A	94 W	-	Standard	21 nC	13ns/33ns	400V, 8A, 10Ohm, 15V	42 ns	-40°C ~ 175°C (TJ)	Surface Mount
