Aluminum Electrolytic Capacitors(115368)
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MAL211067602E3CAP ALUM 6000UF 450V SCREW |
3,981 | 202.20 |
RFQ |
Datasheet |
Bulk | 110 PHT-ST | Active | 6000 µF | -10%, +30% | 450 V | 19.1mOhm @ 100Hz | 10000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | - | - | 13.6 mOhms | 1.252 (31.80mm) | 2.992 Dia (76.00mm) | 8.661 (220.00mm) | - | Chassis Mount |
|
CGS434U040X8LCAP ALUM 430000UF 40V SCREW |
3,264 | 328.23 |
RFQ |
Datasheet |
Bulk | CGS | Active | 430000 µF | -10%, +75% | 40 V | 3mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 45.6 A @ 120 Hz | 59.28 A @ 10 kHz | - | - | 3.000 Dia (76.20mm) | 8.625 (219.08mm) | - | Chassis Mount |
|
|
MAL210412223E3CAP ALUM 22000UF 20% 200V SCREW |
2,374 | 203.40 |
RFQ |
Datasheet |
Bulk | 104 PHL-ST | Active | 22000 µF | ±20% | 200 V | 9mOhm @ 100Hz | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 24.6 A @ 100 Hz | - | 7 mOhms | 1.252 (31.80mm) | 2.992 Dia (76.00mm) | 8.886 (225.70mm) | - | Chassis Mount |
|
|
MAL210452223E3CAP ALUM 22000UF 20% 200V SCREW |
2,078 | 203.40 |
RFQ |
Datasheet |
Bulk | 104 PHL-ST | Active | 22000 µF | ±20% | 200 V | 9mOhm @ 100Hz | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 24.6 A @ 100 Hz | - | 7 mOhms | 1.252 (31.80mm) | 2.992 Dia (76.00mm) | 8.886 (225.70mm) | - | Chassis Mount |
|
HES402G450X5LCAP ALUM 4000UF 450V SCREW |
3,270 | 332.51 |
RFQ |
Datasheet |
Bulk | HES | Active | 4000 µF | 0%, +50% | 450 V | 25mOhm @ 120Hz | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 12.7 A @ 120 Hz | 15.621 A @ 10 kHz | - | - | 3.000 Dia (76.20mm) | 5.625 (142.88mm) | - | Chassis Mount |
|
|
MAL210433153E3CAP ALUM 15000UF 20% 250V SCREW |
2,113 | 203.70 |
RFQ |
Datasheet |
Bulk | 104 PHL-ST | Active | 15000 µF | ±20% | 250 V | 10mOhm @ 100Hz | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 22.7 A @ 100 Hz | - | 7 mOhms | 1.252 (31.80mm) | 2.992 Dia (76.00mm) | 8.886 (225.70mm) | - | Chassis Mount |
|
|
MAL210443153E3CAP ALUM 15000UF 20% 250V SCREW |
2,758 | 203.70 |
RFQ |
Datasheet |
Bulk | 104 PHL-ST | Active | 15000 µF | ±20% | 250 V | 9mOhm @ 100Hz | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 25.8 A @ 100 Hz | - | 6 mOhms | 1.252 (31.80mm) | 3.543 Dia (90.00mm) | 6.118 (155.40mm) | - | Chassis Mount |
|
|
MAL210473153E3CAP ALUM 15000UF 20% 250V SCREW |
3,449 | 203.70 |
RFQ |
Datasheet |
Bulk | 104 PHL-ST | Active | 15000 µF | ±20% | 250 V | 10mOhm @ 100Hz | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 22.7 A @ 100 Hz | - | 7 mOhms | 1.252 (31.80mm) | 2.992 Dia (76.00mm) | 8.886 (225.70mm) | - | Chassis Mount |
|
|
MAL210483153E3CAP ALUM 15000UF 20% 250V SCREW |
2,970 | 203.70 |
RFQ |
Datasheet |
Bulk | 104 PHL-ST | Active | 15000 µF | ±20% | 250 V | 9mOhm @ 100Hz | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 25.8 A @ 100 Hz | - | 6 mOhms | 1.252 (31.80mm) | 3.543 Dia (90.00mm) | 6.118 (155.40mm) | - | Chassis Mount |
|
450LSG10000MEFC90X221CAP ALUM 10000UF 20% 450V SCREW |
2,503 | 335.11 |
RFQ |
Datasheet |
Bulk | LSG | Active | 10000 µF | ±20% | 450 V | - | 5000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 22.4 A @ 120 Hz | 31.36 A @ 10 kHz | - | 1.236 (31.40mm) | 3.543 Dia (90.00mm) | 8.819 (224.00mm) | - | Chassis Mount |
|
|
B43720D8478M000CAP ALUM 4700UF 20% 600V SCREW |
3,605 | 204.90 |
RFQ |
Datasheet |
Bulk | B43720 | Active | 4700 µF | ±20% | 600 V | 22mOhm @ 100Hz | 6000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 18.5 A @ 100 Hz | - | - | 1.248 (31.70mm) | 3.543 Dia (90.00mm) | 6.732 (171.00mm) | - | Chassis Mount |
|
MAL210213223E3CAP ALUM 22000UF 20% 250V SCREW |
2,516 | 204.90 |
RFQ |
Datasheet |
Bulk | 102 PHR-ST | Active | 22000 µF | ±20% | 250 V | 9mOhm @ 100Hz | 10000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 29.1 A @ 100 Hz | - | 7 mOhms | 1.252 (31.80mm) | 2.992 Dia (76.00mm) | 8.886 (225.70mm) | - | Chassis Mount |
|
|
MAL210253223E3CAP ALUM 22000UF 20% 250V SCREW |
3,767 | 204.90 |
RFQ |
Datasheet |
Bulk | 102 PHR-ST | Active | 22000 µF | ±20% | 250 V | 9mOhm @ 100Hz | 10000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 29.1 A @ 100 Hz | - | 7 mOhms | 1.252 (31.80mm) | 2.992 Dia (76.00mm) | 8.886 (225.70mm) | - | Chassis Mount |
|
|
MAL210432223E3CAP ALUM 22000UF 20% 200V SCREW |
3,285 | 205.95 |
RFQ |
Datasheet |
Bulk | 104 PHL-ST | Active | 22000 µF | ±20% | 200 V | 9mOhm @ 100Hz | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 24.6 A @ 100 Hz | - | 7 mOhms | 1.252 (31.80mm) | 2.992 Dia (76.00mm) | 8.886 (225.70mm) | - | Chassis Mount |
|
|
MAL210442223E3CAP ALUM 22000UF 20% 200V SCREW |
3,125 | 205.95 |
RFQ |
Datasheet |
Bulk | 104 PHL-ST | Active | 22000 µF | ±20% | 200 V | 8mOhm @ 100Hz | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 28.5 A @ 100 Hz | - | 6 mOhms | 1.252 (31.80mm) | 3.543 Dia (90.00mm) | 6.118 (155.40mm) | - | Chassis Mount |
|
|
MAL210472223E3CAP ALUM 22000UF 20% 200V SCREW |
3,770 | 205.95 |
RFQ |
Datasheet |
Bulk | 104 PHL-ST | Active | 22000 µF | ±20% | 200 V | 9mOhm @ 100Hz | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 24.6 A @ 100 Hz | - | 7 mOhms | 1.252 (31.80mm) | 2.992 Dia (76.00mm) | 8.886 (225.70mm) | - | Chassis Mount |
|
|
MAL210482223E3CAP ALUM 22000UF 20% 200V SCREW |
3,476 | 205.95 |
RFQ |
Datasheet |
Bulk | 104 PHL-ST | Active | 22000 µF | ±20% | 200 V | 8mOhm @ 100Hz | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 28.5 A @ 100 Hz | - | 6 mOhms | 1.252 (31.80mm) | 3.543 Dia (90.00mm) | 6.118 (155.40mm) | - | Chassis Mount |
|
|
MAL210233223E3CAP ALUM 22000UF 20% 250V SCREW |
2,069 | 206.85 |
RFQ |
Datasheet |
Bulk | 102 PHR-ST | Active | 22000 µF | ±20% | 250 V | 9mOhm @ 100Hz | 10000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 29.1 A @ 100 Hz | - | 7 mOhms | 1.252 (31.80mm) | 2.992 Dia (76.00mm) | 8.886 (225.70mm) | - | Chassis Mount |
|
|
MAL210273223E3CAP ALUM 22000UF 20% 250V SCREW |
3,916 | 206.85 |
RFQ |
Datasheet |
Bulk | 102 PHR-ST | Active | 22000 µF | ±20% | 250 V | 9mOhm @ 100Hz | 10000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 29.1 A @ 100 Hz | - | 7 mOhms | 1.252 (31.80mm) | 2.992 Dia (76.00mm) | 8.886 (225.70mm) | - | Chassis Mount |
|
|
MAL210417472E3CAP ALUM 4700UF 20% 450V SCREW |
3,375 | 206.85 |
RFQ |
Datasheet |
Bulk | 104 PHL-ST | Active | 4700 µF | ±20% | 450 V | 33mOhm @ 100Hz | 5000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 14.1 A @ 100 Hz | - | 25 mOhms | 1.252 (31.80mm) | 2.992 Dia (76.00mm) | 8.886 (225.70mm) | - | Chassis Mount |
