| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Packaging | Series | ProductStatus | Type | Material-Core | Inductance | Tolerance | CurrentRating(Amps) | Current-Saturation(Isat) | Shielding | DCResistance(DCR) | Q@Freq | Frequency-SelfResonant | Ratings | OperatingTemperature | InductanceFrequency-Test | Features | MountingType | Size/Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
5800-392-RCFIXED IND 3.9MH 120MA 9.7 OHM TH |
907 | 1.60 |
RFQ |
Datasheet |
Axial | Tray | 5800 | Active | Drum Core, Wirewound | Ferrite | 3.9 mH | ±10% | 120 mA | 180mA | Unshielded | 9.7Ohm Max | - | - | - | -55°C ~ 105°C | 1 kHz | - | Through Hole | - |
|
|
5800-3R9-RCFIXED IND 3.9UH 3.1A 15 MOHM TH |
2,243 | 1.60 |
RFQ |
Datasheet |
Axial | Tray | 5800 | Active | Drum Core, Wirewound | Ferrite | 3.9 µH | ±10% | 3.1 A | 5.8A | Unshielded | 15mOhm Max | - | - | - | -55°C ~ 105°C | 1 kHz | - | Through Hole | - |
|
|
5800-680-RCFIXED IND 68UH 900MA 166 MOHM TH |
2,671 | 1.60 |
RFQ |
Datasheet |
Axial | Tray | 5800 | Active | Drum Core, Wirewound | Ferrite | 68 µH | ±10% | 900 mA | 1.4A | Unshielded | 166mOhm Max | - | - | - | -55°C ~ 105°C | 1 kHz | - | Through Hole | - |
|
|
5800-152-RCFIXED IND 1.5MH 190MA 3.9 OHM TH |
2,629 | 1.60 |
RFQ |
Datasheet |
Axial | Tray | 5800 | Active | Drum Core, Wirewound | Ferrite | 1.5 mH | ±10% | 190 mA | 290mA | Unshielded | 3.9Ohm Max | - | - | - | -55°C ~ 105°C | 1 kHz | - | Through Hole | - |
|
|
5800-332-RCFIXED IND 3.3MH 130MA 8.8 OHM TH |
3,129 | 1.60 |
RFQ |
Datasheet |
Axial | Tray | 5800 | Active | Drum Core, Wirewound | Ferrite | 3.3 mH | ±10% | 130 mA | 200mA | Unshielded | 8.8Ohm Max | - | - | - | -55°C ~ 105°C | 1 kHz | - | Through Hole | - |
|
|
5800-562-RCFIXED IND 5.6MH 100MA 13.8OHM TH |
3,758 | 1.60 |
RFQ |
Datasheet |
Axial | Tray | 5800 | Active | Drum Core, Wirewound | Ferrite | 5.6 mH | ±10% | 100 mA | 150mA | Unshielded | 13.8Ohm Max | - | - | - | -55°C ~ 105°C | 1 kHz | - | Through Hole | - |
|
|
5800-153-RCFIXED IND 15MH 61MA 37.5 OHM TH |
3,406 | 1.60 |
RFQ |
Datasheet |
Axial | Tray | 5800 | Active | Drum Core, Wirewound | Ferrite | 15 mH | ±10% | 61 mA | 90mA | Unshielded | 37.5Ohm Max | - | - | - | -55°C ~ 105°C | 1 kHz | - | Through Hole | - |
|
RL875-472K-RCFIXED IND 4.7MH 120MA 16.7OHM TH |
2,714 | 1.68 |
RFQ |
Datasheet |
Radial, Vertical Cylinder (Open) | Bulk | RL875 | Active | Drum Core, Wirewound | Ferrite | 4.7 mH | ±10% | 120 mA | - | Unshielded | 16.7Ohm Max | 35 @ 252kHz | 1MHz | - | -40°C ~ 105°C | 1 kHz | - | Through Hole | - |
|
RL875-270K-RCIND7.8X7.5MM,27UH10%0.170A,NON-S |
3,725 | 1.68 |
RFQ |
Datasheet |
Radial | Bulk | RL875 | Active | Drum Core, Wirewound | Ferrite | 27 µH | ±10% | 1.7 A | - | Unshielded | 110mOhm Max | 30 @ 2.52MHz | 13MHz | - | -40°C ~ 105°C | 2.52 MHz | - | Through Hole | Radial |
|
9250A-684-RCFIXED IND 680UH 80MA 11.8 OHM TH |
3,541 | 2.24 |
RFQ |
Datasheet |
Axial | Bulk | 9250A | Active | Molded | Ferrite | 680 µH | ±10% | 80 mA | 50mA | Shielded | 11.8Ohm Max | 60 @ 790kHz | 4.5MHz | - | -55°C ~ 125°C | 790 kHz | - | Through Hole | - |
|
PM2110-270K-RCFIXED IND 27UH 8.2A 14 MOHM SMD |
2,439 | 3.36 |
RFQ |
Datasheet |
Nonstandard | Bulk | PM2110 | Active | Toroidal | Iron | 27 µH | ±10% | 8.2 A | - | Unshielded | 14mOhm Max | - | - | - | -55°C ~ 105°C | 1 kHz | - | Surface Mount | - |
|
SRP1580CA-1R0MIND,16.5X15.5X7.7MM,1UH20%,58A,S |
3,695 | 5.66 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | SRP1580CA | Active | - | Metal | 1 µH | ±20% | 58 A | 80A | Shielded | 1.15mOhm Max | 30 @ 100kHz | 28MHz | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - |
|
SRP1513CA-150MIND,16.5X15.5X12.7MM,15UH20%,22A |
2,101 | 3.39 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | SRP1513CA | Active | - | Metal | 15 µH | ±20% | 22 A | 25.5A | Shielded | 7.5mOhm Max | 40 @ 100kHz | 7MHz | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - |
|
2300HT-181-V-RCFIXED IND 180UH 7.2A 55 MOHM TH |
3,185 | 6.53 |
RFQ |
Datasheet |
Radial, Vertical (Open) | Bulk | 2300HT | Active | Toroidal | Iron Powder | 180 µH | ±15% | 7.2 A | - | Shielded | 55mOhm Max | - | - | - | -55°C ~ 200°C | 1 kHz | - | Through Hole | - |
|
|
2300HT-471-V-RCFIXED IND 470UH 4.5A 140 MOHM TH |
3,622 | 6.53 |
RFQ |
Datasheet |
Radial, Vertical (Open) | Bulk | 2300HT | Active | Toroidal | Iron Powder | 470 µH | ±15% | 4.5 A | - | Shielded | 140mOhm Max | - | - | - | -55°C ~ 200°C | 1 kHz | - | Through Hole | - |
|
RL824-221K-RCFIXED IND 220UH 820MA 280MOHM TH |
2,886 | 1.73 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | RL824 | Active | Drum Core, Wirewound | Ferrite | 220 µH | ±10% | 820 mA | - | Unshielded | 280mOhm Max | 35 @ 790kHz | 1.9MHz | - | -55°C ~ 105°C | 1 kHz | - | Through Hole | - |
|
9230-76-RCFIXED IND 220UH 73MA 21 OHM TH |
3,651 | 1.76 |
RFQ |
Datasheet |
Axial | Bulk | 9230 | Active | Molded | Ferrite | 220 µH | ±10% | 73 mA | - | Unshielded | 21Ohm Max | 30 @ 790kHz | 9MHz | - | -55°C ~ 125°C | 790 kHz | - | Through Hole | - |
|
|
9230-60-RCFIXED IND 47UH 165MA 4.5 OHM TH |
2,197 | 1.76 |
RFQ |
Datasheet |
Axial | Bulk | 9230 | Active | Molded | Ferrite | 47 µH | ±10% | 165 mA | - | Unshielded | 4.5Ohm Max | 45 @ 2.5MHz | 20MHz | - | -55°C ~ 125°C | 2.5 MHz | - | Through Hole | - |
|
|
9230-72-RCFIXED IND 150UH 85MA 15 OHM TH |
2,030 | 1.76 |
RFQ |
Datasheet |
Axial | Bulk | 9230 | Active | Molded | Ferrite | 150 µH | ±10% | 85 mA | - | Unshielded | 15Ohm Max | 30 @ 790kHz | 11MHz | - | -55°C ~ 125°C | 790 kHz | - | Through Hole | - |
|
RL181S-183J-RCFIXED IND 18MH 21MA 17 OHM TH |
3,605 | 1.84 |
RFQ |
Datasheet |
Radial, Vertical Cylinder | Bulk | RL181S | Active | Drum Core, Wirewound | Ferrite | 18 mH | ±5% | 21 mA | - | Shielded | 17Ohm Max | 100 @ 50kHz | 190kHz | - | -55°C ~ 105°C | 1 kHz | - | Through Hole | - |
