| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Packaging | Series | ProductStatus | SwitchCircuit | Multiplexer/DemultiplexerCircuit | NumberofCircuits | On-StateResistance(Max) | Channel-to-ChannelMatching(ΔRon) | Voltage-SupplySingle(V+) | Voltage-SupplyDual(V±) | SwitchTime(TonToff)(Max) | -3dbBandwidth | ChargeInjection | ChannelCapacitance(CS(off)CD(off)) | Current-Leakage(IS(off))(Max) | Crosstalk | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AD7511DIJPPROTECTED ANALOG SWITCHES |
2,446 | 0.00 |
RFQ |
Datasheet |
16-DIP (0.300, 7.62mm) | Bulk | - | Active | SPST - NC | 1:1 | 4 | 100Ohm | 1Ohm (Typ) | ±15V | ±15V | 350ns (Typ), 180ns (Typ) | - | - | 8pF, 1pF | 500pA | - | -55°C ~ 125°C | Through Hole |
|
5962-9063501M2ASINGLE-ENDED MUX,8 CHANNEL |
3,833 | 1.00 |
RFQ |
Datasheet |
20-CLCC | Bulk | ADG528A | Active | SP8T | 8:1 | 1 | 450Ohm | 22.5Ohm | 10.8V ~ 16.5V, ±10.8V ~ 16.5V | 10.8V ~ 16.5V, ±10.8V ~ 16.5V | 300ns, 300ns | - | 4pC | 5pF, 22pF | 1nA | - | -55°C ~ 125°C | Surface Mount |
|
|
5962-9201401M2AANALOG MUX SINGLE 4:1 (AD9300) |
3,193 | 1.00 |
RFQ |
Datasheet |
20-CLCC | Bulk | AD9300 | Active | SPST - NO | 1:1 | 4 | - | - | ±16V | ±16V | 45ns, 45ns | - | - | - | - | -70dB @ 10MHz | -55°C ~ 125°C | Surface Mount |
|
AD7502JN/+MULTIPLEXERS/SWITCHES,4 CHANNEL |
3,725 | 1.00 |
RFQ |
Datasheet |
16-DIP (0.300, 7.62mm) | Bulk | - | Active | SP4T | 4:1 | 2 | 300Ohm | 12Ohm | ±15V | ±15V | 800ns, 800ns | - | - | 5pF | 2nA | - | -25°C ~ 85°C | Through Hole |
|
AD7503KN/+MULTIPLEXERS/SWITCHES,8 CHANNEL |
2,383 | 1.00 |
RFQ |
- | Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
AD7502KN/+MULTIPLEXERS/SWITCHES,4 CHANNEL |
2,743 | 1.00 |
RFQ |
Datasheet |
16-DIP (0.300, 7.62mm) | Bulk | - | Active | SP4T | 4:1 | 2 | 300Ohm | 12Ohm | ±15V | ±15V | 800ns, 800ns | - | - | 5pF | 2nA | - | 0°C ~ 70°C (TA) | Through Hole |
|
AD7507SQMULTIPLEXERS/SWITCHES,8 CHANNEL |
2,565 | 1.00 |
RFQ |
Datasheet |
28-CDIP (0.600, 15.24mm) | Bulk | - | Active | SP4T | 4:1 | 2 | - | - | - | - | - | - | - | - | - | - | - | Through Hole |
|
|
ADG222BQQUAD SPST SWITCH |
3,913 | 1.00 |
RFQ |
Datasheet |
16-CDIP (0.300, 7.62mm) | Bulk | ADG222 | Active | SPST - NC | 1:1 | 4 | 90Ohm | 4.5Ohm | ±15V | ±15V | 300ns, 250ns | - | 20pC | 5pF, 5pF | 2nA | -80dB @ 100kHz | -40°C ~ 85°C (TA) | Through Hole |
|
|
ADG221TEQUAD SPST SWITCH |
2,026 | 1.00 |
RFQ |
Datasheet |
20-CLCC | Bulk | ADG221 | Active | SPST - NC | 1:1 | 4 | 90Ohm | 4.5Ohm | ±15V | ±15V | 300ns, 250ns | - | 20pC | 5pF, 5pF | 1nA | -80dB @ 100kHz | -55°C ~ 125°C | Surface Mount |
|
ADG749BKS-R2MULTIPLEXERS/SWITCHES,CMOS |
3,464 | 0.00 |
RFQ |
Datasheet |
6-TSSOP, SC-88, SOT-363 | Bulk | - | Active | SPDT | 2:1 | 1 | 5Ohm | 100mOhm | 1.8V ~ 5.5V | 1.8V ~ 5.5V | 7ns (Typ), 3ns (Typ) | 200MHz | - | 7pF | 250pA | -82dB @ 1MHz | -40°C ~ 125°C | Surface Mount |
|
|
ADG507AKN/+DIFFERENTIAL MUX,8 CHANNEL |
3,993 | 1.00 |
RFQ |
Datasheet |
28-DIP (0.600, 15.24mm) | Bulk | LC²MOS | Active | - | 8:1 | 2 | 300Ohm | 15Ohm | 10.8V ~ 16.5V, ±10.8V ~ 16.5V | 10.8V ~ 16.5V, ±10.8V ~ 16.5V | 300ns, 300ns | - | 4pC | 5pF, 22pF | 1nA | - | -40°C ~ 85°C | Through Hole |
|
ADG412BRUPRECISION QUAD SPST SWITCH |
3,139 | 1.00 |
RFQ |
Datasheet |
16-TSSOP (0.173, 4.40mm Width) | Bulk | ADG412 | Active | SPST - NC | 1:1 | 4 | 35Ohm | - | 10.8V ~ 13.2V, ±13.5V ~ 16.5V | 10.8V ~ 13.2V, ±13.5V ~ 16.5V | 175ns, 145ns | - | 5pC | 9pF, 9pF | 250pA | -85dB @ 1MHz | -40°C ~ 85°C | Surface Mount |
|
ADG904BCPZ-R-REEL4:1 MUX/SP4T |
3,860 | 1.00 |
RFQ |
Datasheet |
20-WFQFN Exposed Pad, CSP | Bulk | - | Active | SP4T | 4:1 | 1 | - | - | 1.65V ~ 2.75V | 1.65V ~ 2.75V | 10ns, 16ns | 2.5GHz | - | 2pF | - | -58dB @ 100MHz | -40°C ~ 85°C (TA) | Surface Mount |
|
SW202GSQUAD SPST JFET SWITCH |
2,480 | 1.00 |
RFQ |
Datasheet |
16-SOIC (0.154, 3.90mm Width) | Bulk | - | Active | SPST - NO | 1:1 | 4 | 150Ohm | 30Ohm | ±15V | ±15V | 700ns, 500ns | - | - | 7pF | 10nA | - | -40°C ~ 85°C (TA) | Surface Mount |
|
|
MUX08BRC/883C8-CH JFET ANALOG MULTIPLEXERS |
2,092 | 0.00 |
RFQ |
Datasheet |
20-CLCC | Bulk | - | Active | - | 8:1 | 1 | 400Ohm | 80Ohm | - | - | 2µs, 400ns | - | - | 2.5pF, 7pF | 1nA | -70dB @ 500kHz | -55°C ~ 125°C | Surface Mount |
|
ADG741BKSZ5-REEL7IC SWITCH SPST SC70-5 |
5,223 | 2.78 |
RFQ |
Datasheet |
5-TSSOP, SC-70-5, SOT-353 | Tape & Reel (TR),Cut Tape (CT),Bulk | - | Active | SPST - NO | 1:1 | 1 | 3Ohm | - | 1.8V ~ 5.5V | - | 12ns, 8ns (Typ) | 200MHz | 5pC | 17pF, 17pF | 250pA | - | -40°C ~ 85°C (TA) | Surface Mount |
|
ADG659WYRUZ-REEL7IC MULTIPLEXER DUAL 8:1 16TSSOP |
2,356 | 1.00 |
RFQ |
16-TSSOP (0.173, 4.40mm Width) | Tape & Reel (TR),Cut Tape (CT),Bulk | Automotive | Active | SP4T | 4:1 | 2 | 75Ohm | 1.3Ohm | 2V ~ 12V | ±2V ~ 6V | 115ns, 45ns | 400MHz | 2pC | 4pF, 12pF | 200pA | -90dB @ 1MHz | -40°C ~ 125°C (TA) | Surface Mount | |
|
ADG1213YCPZ-REEL7IC SWITCH QUAD SPST 16LFCSP |
2,107 | 5.30 |
RFQ |
Datasheet |
16-WFQFN Exposed Pad, CSP | Tape & Reel (TR),Cut Tape (CT),Bulk | - | Active | SPST - NO/NC | 1:1 | 4 | 190Ohm | 2.5Ohm | 5V ~ 16.5V | ±4.5V ~ 16.5V | 130ns, 115ns | 1GHz | -0.3pC | 1.1pF, 1.2pF | 100pA | -90dB @ 1MHz | -40°C ~ 125°C (TA) | Surface Mount |
|
ADG1604BRUZ-REELIC MULTIPLEXER 4X1 14TSSOP |
2,229 | 5.30 |
RFQ |
Datasheet |
14-TSSOP (0.173, 4.40mm Width) | Tape & Reel (TR),Cut Tape (CT) | - | Active | SP4T | 4:1 | 1 | 1.1Ohm | 30mOhm | 3.3V ~ 16V | ±3.3V ~ 8V | 95ns, 173ns | 19MHz | 125pC | 60pF, 270pF | 200pA | -70dB @ 1MHz | -40°C ~ 125°C (TA) | Surface Mount |
|
ADG749BKSZ-REEL7IC SWITCH SPDT SC70-6 |
3,425 | 1.00 |
RFQ |
Datasheet |
6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR),Cut Tape (CT),Bulk | - | Active | SPDT | 2:1 | 1 | 5Ohm | - | 1.8V ~ 5.5V | - | 7ns, 3ns (Typ) | 200MHz | - | 7pF | 250pA | -82dB @ 1MHz | -40°C ~ 125°C (TA) | Surface Mount |
