| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
BSC034N10LS5ATMA1MOSFET N-CH 100V 19A/100A TDSON |
3,156 | 4.28 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | OptiMOS™ 5 | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 19A (Ta), 100A (Tc) | 4.5V, 10V | 3.4mOhm @ 50A, 10V | 2.3V @ 115µA | 46 nC @ 4.5 V | ±20V | 6500 pF @ 50 V | - | 2.5W (Ta), 156W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
IPB015N08N5ATMA1MOSFET N-CH 80V 180A TO263-7 |
3,305 | 8.25 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | OptiMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 80 V | 180A (Tc) | 6V, 10V | 1.5mOhm @ 100A, 10V | 3.8V @ 279µA | 222 nC @ 10 V | ±20V | 16900 pF @ 40 V | - | 375W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
IAUS300N08S5N011TATMA1MOSFET N-CH 80V 300A HDSOP-16-2 |
2,861 | 8.26 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | OptiMOS™ 5 | Active | N-Channel | MOSFET (Metal Oxide) | 80 V | 300A (Tj) | 6V, 10V | 1.1mOhm @ 100A, 10V | 3.8V @ 275µA | 231 nC @ 10 V | ±20V | 16250 pF @ 40 V | - | 375W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
AUIRFS3107TRLMOSFET N-CH 75V 195A D2PAK |
2,388 | 7.84 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101, HEXFET® | Not For New Designs | N-Channel | MOSFET (Metal Oxide) | 75 V | 195A (Tc) | 10V | 3mOhm @ 140A, 10V | 4V @ 250µA | 240 nC @ 10 V | ±20V | 9370 pF @ 50 V | - | 370W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
IRFB4110PBFMOSFET N-CH 100V 120A TO220AB |
4,880 | 5.16 |
RFQ |
Datasheet |
Tube | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 120A (Tc) | 10V | 4.5mOhm @ 75A, 10V | 4V @ 250µA | 210 nC @ 10 V | ±20V | 9620 pF @ 50 V | - | 370W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
ISC011N06LM5ATMA1TRENCH 40<-<100V PG-TDSON-8 |
3,359 | 4.42 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | OptiMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 37A (Ta), 288A (Tc) | 4.5V, 10V | 1.15mOhm @ 50A, 10V | 2.3V @ 116µA | 170 nC @ 10 V | ±20V | 11000 pF @ 30 V | - | 3W (Ta), 188W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
IPT007N06NATMA1MOSFET N-CH 60V 300A 8HSOF |
3,631 | 8.56 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | OptiMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 300A (Tc) | 6V, 10V | 0.75mOhm @ 150A, 10V | 3.3V @ 280µA | 287 nC @ 10 V | ±20V | 16000 pF @ 30 V | - | 375W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
IPT010N08NM5ATMA1TRENCH 40<-<100V PG-HSOF-8 |
2,079 | 8.59 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | OptiMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 80 V | 43A (Ta), 425A (Tc) | 6V, 10V | 1.05mOhm @ 150A, 10V | 3.8V @ 280µA | 223 nC @ 10 V | ±20V | 16000 pF @ 40 V | - | 3.8W (Ta), 375W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
IPB010N06NATMA1MOSFET N-CH 60V 45A/180A TO263-7 |
3,267 | 8.62 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | OptiMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 45A (Ta), 180A (Tc) | 6V, 10V | 1mOhm @ 100A, 10V | 4V @ 280µA | 208 nC @ 10 V | ±20V | 15000 pF @ 30 V | - | 300W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
IPB065N15N3GATMA1MOSFET N-CH 150V 130A TO263-7 |
3,833 | 8.69 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | OptiMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 150 V | 130A (Tc) | 8V, 10V | 6.5mOhm @ 100A, 10V | 4V @ 270µA | 93 nC @ 10 V | ±20V | 7300 pF @ 75 V | - | 300W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
IRFP3703PBFMOSFET N-CH 30V 210A TO247AC |
1,109 | 5.48 |
RFQ |
Datasheet |
Bulk,Tube | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 210A (Tc) | 7V, 10V | 2.8mOhm @ 76A, 10V | 4V @ 250µA | 209 nC @ 10 V | ±20V | 8250 pF @ 25 V | - | 3.8W (Ta), 230W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
|
IRFP4310ZPBFMOSFET N-CH 100V 120A TO247AC |
2,493 | 5.50 |
RFQ |
Datasheet |
Tube | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 120A (Tc) | 10V | 6mOhm @ 75A, 10V | 4V @ 150µA | 170 nC @ 10 V | ±20V | 6860 pF @ 50 V | - | 280W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
|
IPTC012N08NM5ATMA1MOSFET N-CH 80V 40A/396A HDSOP |
3,932 | 9.19 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | OptiMOS™ 5 | Active | N-Channel | MOSFET (Metal Oxide) | 80 V | 40A (Ta), 396A (Tc) | 6V, 10V | 1.2mOhm @ 100A, 10V | 3.8V @ 275µA | 219 nC @ 10 V | ±20V | 16000 pF @ 40 V | - | 3.8W (Ta), 375W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
IPB107N20N3GATMA1MOSFET N-CH 200V 88A D2PAK |
2,079 | 9.34 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | OptiMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 200 V | 88A (Tc) | 10V | 10.7mOhm @ 88A, 10V | 4V @ 270µA | 87 nC @ 10 V | ±20V | 7100 pF @ 100 V | - | 300W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
IRFP4321PBFMOSFET N-CH 150V 78A TO247AC |
3,271 | 5.74 |
RFQ |
Datasheet |
Tube | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 150 V | 78A (Tc) | 10V | 15.5mOhm @ 33A, 10V | 5V @ 250µA | 110 nC @ 10 V | ±30V | 4460 pF @ 25 V | - | 310W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
IPL60R065P7AUMA1MOSFET N-CH 650V 41A 4VSON |
2,116 | 9.39 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | CoolMOS™ P7 | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 41A (Tc) | 10V | 65mOhm @ 15.9A, 10V | 4V @ 800µA | 67 nC @ 10 V | ±20V | 2895 pF @ 400 V | - | 201W (Tc) | -40°C ~ 150°C (TJ) | Surface Mount |
|
|
AUIRFS8407-7PMOSFET N-CH 40V 240A D2PAK-7 |
2,766 | 5.76 |
RFQ |
Datasheet |
Tube | HEXFET® | Not For New Designs | N-Channel | MOSFET (Metal Oxide) | 40 V | 240A (Tc) | 10V | 1.3mOhm @ 100A, 10V | 3.9V @ 150µA | 225 nC @ 10 V | ±20V | 7437 pF @ 25 V | - | 231W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
IPB020N10N5LFATMA1MOSFET N-CH 100V 120A TO263-3 |
3,122 | 9.63 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | OptiMOS™-5 | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 120A (Tc) | 10V | 2mOhm @ 100A, 10V | 4.1V @ 270µA | 195 nC @ 10 V | ±20V | 840 pF @ 50 V | - | 313W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
IPL60R060CFD7AUMA1MOSFET N CH |
3,158 | 9.72 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | CoolMOS™ CFD7 | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 40A (Tc) | 10V | 60mOhm @ 18A, 10V | 4.5V @ 900µA | 79 nC @ 10 V | ±20V | 3193 pF @ 400 V | - | 219W (Tc) | -40°C ~ 150°C (TJ) | Surface Mount |
|
|
IPB044N15N5ATMA1MOSFET N-CH 150V 174A TO263-7 |
3,828 | 10.05 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | OptiMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 150 V | 174A (Tc) | 8V, 10V | 4.4mOhm @ 87A, 10V | 4.6V @ 264µA | 100 nC @ 10 V | ±20V | 8000 pF @ 75 V | - | 300W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
