| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | DiodeConfiguration | DiodeType | Voltage-DCReverse(Vr)(Max) | Current-AverageRectified(Io)(perDiode) | Voltage-Forward(Vf)(Max)@If | Speed | ReverseRecoveryTime(trr) | Current-ReverseLeakage@Vr | OperatingTemperature-Junction | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
BYV32-100-E3/45DIODE ARRAY GP 100V 18A TO220AB |
633 | 1.74 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Cathode | Standard | 100 V | 18A | 1.15 V @ 20 A | Fast Recovery =< 500ns, > 200mA (Io) | 25 ns | 10 µA @ 100 V | -65°C ~ 150°C | Through Hole |
|
|
V30100C-M3/4WDIODE SCHOTTKY 30A 100V TO-220AB |
944 | 1.75 |
RFQ |
Datasheet |
Tube | Automotive, AEC-Q101, TMBS® | Active | 1 Pair Common Cathode | Schottky | 100 V | 15A | 800 mV @ 15 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 500 µA @ 100 V | -40°C ~ 150°C | Through Hole |
|
VF20200C-E3/4WDIODE ARRAY SCHOTTKY 200V ITO220 |
903 | 1.76 |
RFQ |
Datasheet |
Tube | TMBS® | Active | 1 Pair Common Cathode | Schottky | 200 V | 10A | 1.6 V @ 10 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 150 µA @ 200 V | -40°C ~ 150°C | Through Hole |
|
FEPB16JT-E3/45DIODE ARRAY GP 600V 8A TO263AB |
895 | 1.78 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Cathode | Standard | 600 V | 8A | 1.5 V @ 8 A | Fast Recovery =< 500ns, > 200mA (Io) | 50 ns | 10 µA @ 600 V | -55°C ~ 150°C | Surface Mount |
|
|
V30120C-M3/4WDIODE SCHOTTKY 30A 120V TO-220AB |
929 | 1.82 |
RFQ |
Datasheet |
Tube | TMBS® | Active | 1 Pair Common Cathode | Schottky | 120 V | 15A | 970 mV @ 15 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 800 µA @ 120 V | -40°C ~ 150°C | Through Hole |
|
|
V30120C-E3/4WDIODE ARRAY SCHOTTKY 120V TO220 |
990 | 1.88 |
RFQ |
Datasheet |
Tube | TMBS® | Active | 1 Pair Common Cathode | Schottky | 120 V | 15A | 970 mV @ 15 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 800 µA @ 120 V | -40°C ~ 150°C | Through Hole |
|
|
MBR2560CT-E3/45DIODE ARRAY SCHOTTKY 60V TO220AB |
333 | 1.92 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Cathode | Schottky | 60 V | 15A | 750 mV @ 15 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 1 mA @ 60 V | -65°C ~ 150°C | Through Hole |
|
|
VF30150C-E3/4WDIODE ARRAY SCHOTTKY 150V ITO220 |
662 | 2.37 |
RFQ |
Datasheet |
Tube | TMBS® | Active | 1 Pair Common Cathode | Schottky | 150 V | 15A | 1.36 V @ 15 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 200 µA @ 150 V | -55°C ~ 150°C | Through Hole |
|
|
V40120C-E3/4WDIODE ARRAY SCHOTTKY 120V TO220 |
788 | 2.38 |
RFQ |
Datasheet |
Tube | TMBS® | Active | 1 Pair Common Cathode | Schottky | 120 V | 20A | 880 mV @ 20 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 500 µA @ 120 V | -40°C ~ 150°C | Through Hole |
|
VI40120C-E3/4WDIODE ARRAY SCHOTTKY 120V TO262 |
708 | 2.77 |
RFQ |
Datasheet |
Tube | TMBS® | Active | 1 Pair Common Cathode | Schottky | 120 V | 20A | 880 mV @ 20 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 500 µA @ 120 V | -40°C ~ 150°C | Through Hole |
|
|
VS-20CTH03FP-N3DIODE ARRAY GP 300V 10A TO220FP |
3,163 | 2.81 |
RFQ |
Datasheet |
Tube | FRED Pt® | Active | 1 Pair Common Cathode | Standard | 300 V | 10A | 1.25 V @ 10 A | Fast Recovery =< 500ns, > 200mA (Io) | 31 ns | 20 µA @ 300 V | -65°C ~ 175°C | Through Hole |
|
|
VI40100C-E3/4WDIODE ARRAY SCHOTTKY 100V TO262 |
3,143 | 2.91 |
RFQ |
Datasheet |
Tube | TMBS® | Active | 1 Pair Common Cathode | Schottky | 100 V | 20A | 730 mV @ 20 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 1 mA @ 100 V | -40°C ~ 150°C | Through Hole |
;;3.jpg)
|
M6060P-E3/45DIODE ARRAY SCHOTTKY 60V TO3P |
405 | 2.94 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Cathode | Schottky | 60 V | 30A | 640 mV @ 30 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 600 µA @ 60 V | -65°C ~ 150°C | Through Hole |
|
|
MBR3060PT-E3/45DIODE ARRAY SCHOTTKY 60V TO3P |
434 | 3.04 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Cathode | Schottky | 60 V | 20A | 750 mV @ 20 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 5 mA @ 60 V | -65°C ~ 150°C | Through Hole |
|
VS-VSKC166/04PBFDIODE MODULE 400V INT-A-PAK |
3,799 | 63.40 |
RFQ |
Datasheet |
Bulk | - | Active | 1 Pair Common Cathode | Standard | 400 V | 165A | - | Standard Recovery >500ns, > 200mA (Io) | - | - | - | Chassis Mount |
|
VS-CZH6106FP-M32X30A (COMMON CATHODE), 600V, FR |
167 | 0.46 |
RFQ |
Datasheet |
Tube | FRED Pt® | Active | 1 Pair Common Cathode | Standard | 600 V | 30A | 2.15 V @ 30 A | Fast Recovery =< 500ns, > 200mA (Io) | 90 ns | 10 µA @ 600 V | -55°C ~ 175°C | Through Hole |
|
|
VS-MURB1620CTLHM3DIODE STANDARD 200V 8A TO263AB |
800 | 2.06 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101, FRED Pt® | Active | 1 Pair Common Cathode | Standard | 200 V | 8A | 975 mV @ 8 A | Fast Recovery =< 500ns, > 200mA (Io) | 20 ns | 250 µA @ 200 V | -65°C ~ 175°C | Surface Mount |
|
|
V20150C-E3/4WDIODE ARRAY SCHOTTKY 150V TO220 |
2,111 | 1.68 |
RFQ |
Datasheet |
Tube | TMBS® | Active | 1 Pair Common Cathode | Schottky | 150 V | 10A | 1.2 V @ 10 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 150 µA @ 150 V | -55°C ~ 150°C | Through Hole |
|
|
MBR10H100CT-E3/45DIODE ARRAY SCHOTTKY 100V TO220 |
976 | 1.72 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Cathode | Schottky | 100 V | 5A | 760 mV @ 5 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 3.5 µA @ 100 V | -65°C ~ 175°C | Through Hole |
|
|
VS-MURB2020CTHM3DIODE STANDARD 200V 10A D2PAK |
950 | 2.05 |
RFQ |
Datasheet |
Tube | Automotive, AEC-Q101, FRED Pt® | Active | 1 Pair Common Cathode | Standard | 200 V | 10A | 850 mV @ 8 A | Fast Recovery =< 500ns, > 200mA (Io) | 21 ns | 15 µA @ 200 V | -65°C ~ 175°C | Surface Mount |
