| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | RoHS | Speed | Diode Type | Part Status | Mounting Type | Capacitance @ Vr, F | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Operating Temperature | Voltage - Forward (Vf) (Max) @ If |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
JAN1N5809/TRRECTIFIER UFR,FRR |
3,339 | 6.53 |
RFQ |
Datasheet |
Tape & Reel (TR) | Military, MIL-PRF-19500/477 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 60pF @ 10V, 1MHz | 30 ns | 5 µA @ 100 V | 100 V | 6A | -65°C ~ 175°C | 875 mV @ 4 A |
|
USD345CRECTIFIER |
3,597 | 82.26 |
RFQ |
Datasheet |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Schottky | Active | Through Hole | - | - | 10 mA @ 45 V | 45 V | 30A | 175°C (Max) | 660 mV @ 20 A | |
|
|
JAN1N5811/TRRECTIFIER UFR,FRR |
3,967 | 6.53 |
RFQ |
Datasheet |
Tape & Reel (TR) | Military, MIL-PRF-19500/477 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 60pF @ 10V, 1MHz | 30 ns | 5 µA @ 150 V | 150 V | 6A | -65°C ~ 175°C | 875 mV @ 4 A |
|
JAN1N5417/TRRECTIFIER UFR,FRR |
3,325 | 6.53 |
RFQ |
Datasheet |
Tape & Reel (TR) | Military, MIL-PRF-19500/411 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 150 ns | 1 µA @ 200 V | 200 V | 3A | -65°C ~ 175°C | 1.5 V @ 9 A |
|
JAN1N5806US/TRRECTIFIER UFR,FRR |
3,490 | 6.53 |
RFQ |
Datasheet |
Tape & Reel (TR) | Military, MIL-PRF-19500/477 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 25pF @ 10V, 1MHz | 25 ns | 1 µA @ 150 V | 150 V | 2.5A | -65°C ~ 175°C | 975 mV @ 2.5 A |
|
|
1N3294ASTANDARD RECTIFIER |
2,912 | 82.37 |
RFQ |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Stud Mount | - | - | 13 mA @ 800 V | 800 V | 100A | -65°C ~ 200°C | 1.1 V @ 200 A | ||
|
1N6661/TRSTD RECTIFIER |
2,129 | 6.54 |
RFQ |
Datasheet |
Tape & Reel (TR) | Military, MIL-PRF- 19500/587 | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Through Hole | - | - | 50 nA @ 225 V | 225 V | 500mA | -65°C ~ 175°C | 1 V @ 400 mA |
|
|
1N3294STANDARD RECTIFIER |
3,910 | 82.37 |
RFQ |
Datasheet |
Bulk | RoHS | - | - | Active | - | - | - | - | - | - | - | - | |
|
|
1N5811USE3RECTIFIER DIODE |
3,162 | 6.56 |
RFQ |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 30 ns | - | 150 V | 3A | -65°C ~ 175°C | 875 mV @ 4 A | ||
|
|
JANTX1N5822SCHOTTKY DIODE |
2,082 | 82.50 |
RFQ |
Bulk | Military, MIL-PRF-19500/620 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Through Hole | - | - | 100 µA @ 40 V | 40 V | 3A | -65°C ~ 125°C | 500 mV @ 3 A | |
|
1N6639DIODE GEN PURPOSE |
2,923 | 6.56 |
RFQ |
Bulk | Military, MIL-PRF-19500/609 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 4 ns | - | 75 V | 300mA | -65°C ~ 175°C | 1.2 V @ 500 mA | |
|
|
1N6640DIODE GEN PURPOSE |
3,072 | 6.56 |
RFQ |
Bulk | RoHS | - | - | Active | - | - | - | - | - | - | - | - | ||
|
|
JANTX1N5822/TRDIODE SMALL-SIGNAL SCHOTTKY |
3,403 | 82.65 |
RFQ |
Datasheet |
Tape & Reel (TR) | Military, MIL-PRF-19500/620 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Through Hole | - | - | 100 µA @ 40 V | 40 V | 3A | -65°C ~ 125°C | 500 mV @ 3 A |
|
|
JANTX1N5188DIODE GEN PURP 400V 3A AXIAL |
3,897 | 10.35 |
RFQ |
Datasheet |
Bulk | Military, MIL-PRF-19500/424 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 250 ns | 2 µA @ 400 V | 400 V | 3A | -65°C ~ 175°C | 1.5 V @ 9 A |
|
|
JANTXV1N5621DIODE GEN PURP 800V 1A AXIAL |
3,660 | 10.35 |
RFQ |
Datasheet |
Bulk | Military, MIL-PRF-19500/429 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 20pF @ 12V, 1MHz | 300 ns | 500 nA @ 800 V | 800 V | 1A | -65°C ~ 175°C | 1.6 V @ 3 A |
|
|
JANTXV1N6639DIODE GEN PURP 75V 300MA AXIAL |
2,458 | 10.35 |
RFQ |
Datasheet |
Bulk | Military, MIL-PRF-19500/609 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 4 ns | 100 nA @ 75 V | 75 V | 300mA | -65°C ~ 175°C | 1.2 V @ 500 mA |
|
|
JANTXV1N6641DIODE GEN PURP 50V 300MA AXIAL |
3,763 | 10.35 |
RFQ |
Datasheet |
Bulk | Military, MIL-PRF-19500/609 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 5 ns | 100 nA @ 50 V | 50 V | 300mA | -65°C ~ 175°C | 1.1 V @ 200 mA |
|
|
JANTXV1N6643DIODE GEN PURP 75V 300MA AXIAL |
3,333 | 10.35 |
RFQ |
Datasheet |
Bulk | Military, MIL-PRF-19500/578 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 5pF @ 0V, 1MHz | 20 ns | 500 nA @ 75 V | 75 V | 300mA | -65°C ~ 175°C | 1.2 V @ 100 mA |
|
|
JANTXV1N6640SWITCHING DIODE |
2,883 | 10.35 |
RFQ |
Bulk | Military, MIL-PRF-19500/609 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 4 ns | 100 nA @ 50 V | 50 V | 300mA | -65°C ~ 175°C | 1 V @ 200 mA | |
|
1N6625DIODE GEN PURP 1.1KV 1A AXIAL |
2,783 | 10.37 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 10pF @ 10V, 1MHz | 60 ns | 1 µA @ 1100 V | 1100 V | 1A | -65°C ~ 150°C | 1.75 V @ 1 A |
