| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Packaging | Series | ProductStatus | Type | Material-Core | Inductance | Tolerance | CurrentRating(Amps) | Current-Saturation(Isat) | Shielding | DCResistance(DCR) | Q@Freq | Frequency-SelfResonant | Ratings | OperatingTemperature | InductanceFrequency-Test | Features | MountingType | Size/Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CTM1F-820K82UH AXIAL MOLDED INDUCTOR |
197 | 1.21 |
RFQ |
Datasheet |
Axial | Tape & Reel (TR) | CTM1F | Active | Molded | Ferrite | 82 µH | ±10% | 88 mA | - | Unshielded | 7.3Ohm Max | 50 @ 2.5MHz | 14MHz | - | -55°C ~ 105°C | 2.5 MHz | - | Through Hole | Axial |
|
|
CTM1F-R39K.39UH AXIAL MOLDED INDUCTOR |
100 | 1.21 |
RFQ |
Datasheet |
Axial | Tape & Reel (TR) | CTM1F | Active | Molded | Phenolic | 390 nH | ±10% | 700 mA | - | Unshielded | 300mOhm Max | 30 @ 25MHz | 365MHz | - | -55°C ~ 105°C | 25 MHz | - | Through Hole | Axial |
|
CTGSR105BF-101M100UH SMD SHIELDED POWR INDUCTOR |
100 | 1.21 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR) | CTGSR105BF | Active | - | - | 100 µH | ±20% | 720 mA | - | Shielded | 340mOhm Max | - | - | - | -30°C ~ 100°C | 1 kHz | - | Surface Mount | - |
|
|
CTM1F-1R0K1.0UH AXIAL MOLDED INDUCTOR |
600 | 1.21 |
RFQ |
Datasheet |
Axial | Tape & Reel (TR) | CTM1F | Active | Molded | Phenolic | 1 µH | ±10% | 385 mA | - | Unshielded | 1Ohm Max | 25 @ 25MHz | 230MHz | - | -55°C ~ 105°C | 25 MHz | - | Through Hole | Axial |
|
|
CTM1F-3R9K3.9UH AXIAL MOLDED INDUCTOR |
100 | 1.21 |
RFQ |
Datasheet |
Axial | Tape & Reel (TR) | CTM1F | Active | Molded | Ferrite | 3.9 µH | ±10% | 250 mA | - | Unshielded | 1Ohm Max | 45 @ 7.9MHz | 80MHz | - | -55°C ~ 105°C | 7.9 MHz | - | Through Hole | Axial |
|
|
CTM1F-151K150UH AXIAL MOLDED INDUCTOR |
2,503 | 1.21 |
RFQ |
Datasheet |
Axial | Tape & Reel (TR) | CTM1F | Active | Molded | Ferrite | 150 µH | ±10% | 61 mA | - | Unshielded | 15Ohm Max | 30 @ 790kHz | 11MHz | - | -55°C ~ 105°C | 790 kHz | - | Through Hole | Axial |
|
|
CTM1F-102J1000UH AXIAL MOLDED INDUCTR |
3,690 | 1.21 |
RFQ |
Datasheet |
Axial | Tape & Reel (TR) | CTM1F | Active | Molded | Ferrite | 1 mH | ±5% | 28 mA | - | Unshielded | 72Ohm Max | 30 @ 790kHz | 3.4MHz | - | -55°C ~ 105°C | 790 kHz | - | Through Hole | Axial |
|
|
CTM1F-R82HAXIAL MOLDED INDUCTOR |
2,089 | 1.21 |
RFQ |
Datasheet |
Axial | Tape & Reel (TR) | CTM1F | Active | Molded | Phenolic | 820 nH | - | 415 mA | - | Unshielded | 850mOhm Max | 28 @ 25MHz | 250MHz | - | -55°C ~ 105°C | 25 MHz | - | Through Hole | Axial |
|
|
CTM1F-R56K.56UH AXIAL MOLDED INDUCTOR |
2,860 | 1.21 |
RFQ |
Datasheet |
Axial | Tape & Reel (TR) | CTM1F | Active | Molded | Phenolic | 560 nH | ±10% | 545 mA | - | Unshielded | 500mOhm Max | 30 @ 25MHz | 300MHz | - | -55°C ~ 105°C | 25 MHz | - | Through Hole | Axial |
|
CTIHLP2208F-4R7M4.7UH SMD SHLDED POWER INDUCTOR |
3,475 | 1.27 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR) | CTIHLP2208F | Active | - | - | 4.7 µH | ±20% | 3 A | 5A | Shielded | 90mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
CTIHLP2208F-1R5M1.5UH SMD SHLDED POWER INDUCTOR |
3,763 | 1.27 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR) | CTIHLP2208F | Active | - | - | 1.5 µH | ±20% | 5.5 A | 6.5A | Shielded | 35mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
CTIHLP2208F-1R0M1.0UH SMD SHLDED POWER INDUCTOR |
2,392 | 1.27 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR) | CTIHLP2208F | Active | - | - | 1 µH | ±20% | 6 A | 7A | Shielded | 30mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
CTSLF1275TF-100MSMD SHIELDED POWER INDUCTOR |
2,668 | 1.32 |
RFQ |
Nonstandard | Tape & Reel (TR) | CTSLF1275TF | Active | - | - | 10 µH | ±20% | 5.5 A | 5.4A | Shielded | 15.6mOhm | - | - | - | -40°C ~ 125°C | 1 kHz | - | Surface Mount | - | |
|
CTIHLP5015F-R82M0.82UH SMD SHLDED POWER INDUCTOR |
3,487 | 1.36 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR) | CTIHLP5015F | Active | - | - | 820 nH | ±20% | 25 A | 44A | Shielded | 3mOhm Max | - | - | - | -55°C ~ 125°C | 200 kHz | - | Surface Mount | - |
|
CTDS1608CF-33333UH SMD SHIELDED POWER INDUCTOR |
3,469 | 1.46 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR) | CTDS1608CF | Active | - | - | 33 µH | ±20% | 600 mA | - | Shielded | 190mOhm Max | 40 @ 100kHz | 20MHz | - | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - |
|
|
CTDS1608CF-22322UH SMD SHIELDED POWER INDUCTOR |
2,985 | 1.46 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR) | CTDS1608CF | Active | - | - | 22 µH | ±20% | 700 mA | - | Shielded | 110mOhm Max | 40 @ 100kHz | 25MHz | - | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - |
|
CTSDB1105F-220M22UH SMD SHLDED POWER INDUCTOR |
3,438 | 1.81 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR) | CTSDB1105F | Active | - | - | 22 µH | ±20% | - | 2.1A | Shielded | 80mOhm Max | - | - | - | -25°C ~ 75°C | 1 kHz | - | Surface Mount | - |
|
CTEP125SF-1R5M1.5UH SMD SHLDED POWER INDUCTOR |
3,081 | 1.82 |
RFQ |
Datasheet |
Nonstandard | Tape & Reel (TR) | CTEP125SF | Active | Wirewound | - | 1.5 µH | ±20% | - | 14A | Shielded | 2.5mOhm Max | - | - | - | -30°C ~ 100°C | 100 kHz | - | Surface Mount | - |
|
CTH8F-100K10UH AXIAL PWR LINE INDUCTOR |
100 | 2.34 |
RFQ |
Datasheet |
Axial | Bulk | CTH8F | Active | - | - | 10 µH | ±10% | 4 A | 8.7A | Unshielded | 17mOhm Max | - | 20MHz | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Axial |
|
|
CTH8F-471K470UH AXIAL PWR LINE INDUCTOR |
2,556 | 2.34 |
RFQ |
Datasheet |
Axial | Bulk | CTH8F | Active | - | - | 470 µH | ±10% | 1.2 A | 1.24A | Unshielded | 380mOhm Max | - | 1MHz | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Axial |
